SIEMENS 6SL3200-0ST07-0AA0 Inverter Connector Kit

Description

SIEMENS 6SL3200-0ST07-0AA0 Inverter Connector Kit

Product Dimensions：

The SIEMENS 6SL3200-0ST07-0AA0 is a specialized accessory within the SINAMICS drive family. Specifically, it is the Shield Connection Kit (also known as the Shield Plate or Screen Termination Kit) designed for the SINAMICS V20 Frequency Inverter, specifically for Frame Size D (FSD).

1. Product Description

This kit provides an integrated solution for the proper grounding and electromagnetic compatibility (EMC) of power and control cables. In industrial environments, high-frequency interference from motor cables can disrupt sensitive electronics. This shield connection kit ensures that cable shields are grounded directly to the inverter’s chassis with a low-impedance path.

2. Technical Specifications

3. Product Advantages

• EMC Compliance: Significantly reduces Electromagnetic Interference (EMI) by providing a 360-degree shield contact, ensuring the system meets industrial emission standards.

• Mechanical Stability: Acts as a strain relief for motor and power cables, preventing physical stress on the inverter terminals.

• Simplified Installation: Specifically engineered for the V20 FSD housing; it attaches directly to the bottom of the drive without the need for custom drilling.

• Durability: Made of corrosion-resistant materials suitable for harsh industrial cabinet environments.

4. Key Considerations & Precautions

• Frame Size Matching: This kit is only for Frame Size D. Using it on smaller frame sizes (FSA/FSB/FSC) or larger ones (FSE) will result in a physical mismatch.

• Cable Stripping: For the shield to be effective, the outer insulation of the cable must be stripped back so the braided shield makes direct metal-to-metal contact with the clamps.

• Tightening Torque: Ensure mounting screws are tightened to the specified torque in the manual to maintain a low-impedance ground path.

• Safety: Always ensure the inverter is powered off and the DC link capacitors are discharged before installing the kit.

5. Typical Applications

This component is used wherever a SINAMICS V20 (Frame Size D) drive is installed in a system requiring high reliability and noise suppression, such as:

• Pumping & Ventilation: Large-scale HVAC systems and water treatment plants.

• Conveyor Systems: Material handling in manufacturing lines.

• Compressors: Industrial air compression units.

• Processing Machinery: Mixers, grinders, and centrifuges where precise control signals must be protected from motor noise.

.
