Siemens 6GK5206-1BB10-2AA3 Managed Industrial Ethernet Switch

Description

Siemens 6GK5206-1BB10-2AA3 Managed Industrial Ethernet Switch

Product Dimensions：

The Siemens 6GK5206-1BB10-2AA3 is a highly reliable, managed Industrial Ethernet Switch belonging to the SCALANCE X-200 product family, specifically the SCALANCE X206-1 model. It is designed to construct industrial electrical and optical line, star, or ring network structures.

Product Detailed Description

The SCALANCE X206-1 is a managed Layer 2 industrial switch equipped with six 10/100 Mbps RJ45 ports for copper-wired connections and one 100 Mbps multimode BFOC (ST) optical port for fiber optic connections up to 5 km. It integrates seamlessly into automated environments as a PROFINET IO device and features advanced diagnostics, network management, and redundancy capabilities (such as serving as a Redundancy Manager).

Technical Parameters

Product Advantages

• Hybrid Connectivity: Offers a mix of six electrical RJ45 ports for local machines and one ST multimode fiber port for interference-free, long-distance communication (up to 5 km).
• Network Redundancy: Features an integrated redundancy manager which supports high-speed ring configurations (MRP – Media Redundancy Protocol) to ensure rapid recovery times if a network path fails.
• PROFINET Diagnostics: Fully recognized as a PROFINET IO device, allowing diagnostics and network topologies to be managed directly within the Siemens TIA Portal or Step 7 environment.
• C-PLUG Compatibility: If the switch needs to be replaced, the optional C-PLUG configuration storage can be physically swapped into the new unit, instantly transferring all IP addresses, port settings, and security parameters without requiring a PC.
• Robust Hardware: Designed with a fanless, compact housing, redundant power inputs to guard against power failure, and an extreme operating temperature range (-40°C to +60°C).

Important Considerations & Precautions

• Lifecycle Status: This module has entered its product cancellation/phase-out stage as of late 2024. For new installations, ensure spare parts are stocked or consider transitioning to the successor series (e.g., SCALANCE XC-200).
• Dust & Moisture Protection: With an IP30/IP20 enclosure rating, the switch must be mounted in an appropriate control cabinet or IP65/67 enclosure if used in dusty, humid, or outdoor environments.
• Fiber Connector Care: Always keep the dust caps on the BFOC optical port when not in use. Contaminants on the fiber interface can significantly attenuate the optical signal, leading to packet loss.
• Power Supply Sourcing: Ensure both power supply paths (if utilizing redundancy) are properly fused (0.6 A / 60 V) and utilize stable, industrial-grade PELV/SELV 24 V sources.

Product Applications

• Factory Automation: Connecting machines, PLCs, and HMIs on a shop floor to a centralized control room.
• Infrastructure and Sub-stations: Utilizing the optical fiber port to bridge long physical distances between remote pump houses, wind turbines, or railway signals without electromagnetic interference.
• Process Industry: Often applied in plants requiring high availability, using the integrated redundancy manager to configure fault-tolerant optical or copper rings.
• Machine-Level Integration: Perfect for mounting inside compact control cabinets right next to SIMATIC S7-300 or S7-1200/1500 PLC racks.
