Siemens 6AV3607-1JC20-0AX1 Touchscreen

Description

Siemens 6AV3607-1JC20-0AX1 Touchscreen

Product Dimensions：

The Siemens 6AV3607-1JC20-0AX1 belongs to the legacy SIMATIC OP7 (Operator Panel) series. While many of these units are now considered “mature” or discontinued by Siemens, they remain critical components in many existing industrial setups due to their rugged reliability.

1. Detailed Product Description

The SIMATIC OP7/DP is an operator panel designed for machine-level monitoring and control. It acts as the interface between the human operator and the PLC (Programmable Logic Controller). This specific model features a high-contrast LC display and a membrane keyboard, engineered to withstand harsh industrial environments.

2. Technical Parameters

Below are the core specifications for the 6AV3607-1JC20-0AX1:

3. Product Advantages

• Durability: Built with a rugged IP65-rated front panel, making it resistant to dust, moisture, and vibration.

• Compact Design: Ideal for integration into small control cabinets or directly onto machinery where space is limited.

• Tactile Feedback: The membrane keys provide physical confirmation of input, which is often preferred over touchscreens in oily or gloved environments.

• Communication Efficiency: High-speed integration via PROFIBUS-DP ensures rapid data exchange with SIMATIC S7 controllers.

4. Safety & Operational Precautions

• Power Supply: Always ensure a stable 24V DC source. Voltage spikes outside the 18-30V range can damage the internal circuitry.

• Installation: Ensure the sealing gasket is properly seated during mounting to maintain the IP65 waterproof rating.

• Legacy Status: As this is an older model, ensure you have a backup of the original configuration file (using ProTool or WinCC Flexible), as hardware replacements may require firmware migration.

• Cleaning: Use a soft cloth with mild detergent; avoid harsh chemical solvents that can degrade the membrane overlay.

5. Typical Applications

The OP7 is widely used in sectors requiring straightforward text-based diagnostic and control functions:

• Packaging Machinery: Monitoring speeds, counts, and error messages.

• Food & Beverage: Adjusting temperature setpoints and viewing process timers.

• Automotive Lines: Simple station control and status reporting via PROFIBUS.

• Water Treatment: Displaying pump status and flow levels.
