SEW MXP80A-050-503-00 Servo system power module

Description

SEW MXP80A-050-503-00 Servo system power module

Product Dimensions：

The SEW-EURODRIVE MXP80A-050-503-00 is a power supply module from the MOVIAXIS® multi-axis servo inverter series. This specific module is designed to provide DC link power to multiple axis modules within a coordinated drive system.

1. Product Description

The MXP80A-050-503-00 is a Standard Power Supply Module equipped with an integrated brake chopper. It acts as the central energy hub for a MOVIAXIS® system, converting 3-phase AC line voltage into a stabilized DC link voltage ($560\text{ V DC}$) to drive various servo axis modules.

• Series: MOVIAXIS® (Modular Multi-axis Servo Inverter)

• Module Type: MXP (Power Supply Module with Brake Chopper)

• Version: 80 (Standard design)

2. Technical Parameters

3. Product Advantages

• High Dynamics: The $250\%$ overload capacity allows for extremely fast acceleration and high-cycle applications.

• Modular Efficiency: A single supply module can power up to 8 axis modules, reducing cabinet space and wiring complexity.

• Integrated Energy Management: Features a built-in brake chopper to dissipate regenerative energy. It can also be paired with buffer/capacitor modules to store energy.

• Simplified Maintenance: Features a double 7-segment display for immediate status monitoring and error diagnostics.

• Reduced THD: Optimized charging currents ensure low harmonic distortion on the power grid.

4. Precautions & Safety Notes

• Capacitive Loads: Never connect capacitive loads directly to the unit output; only ohmic/inductive loads (motors via axis modules) should be used.

• Heat Dissipation: When using the integrated brake chopper with an external braking resistor, the resistor surfaces can reach $250^\circ\text{C}$. Ensure proper ventilation and clearance.

• Residual Voltage: After disconnecting from the power supply, wait at least 10 minutes for the DC link capacitors to discharge before touching terminals.

• Installation Environment: Ensure the unit is installed in a control cabinet with a pollution degree of 2 or better to prevent internal short circuits.

5. Typical Applications

The MOVIAXIS® system, powered by the MXP80A, is ideally suited for complex, multi-axis automated machinery:

• Material Handling: Gantry cranes, stacker cranes, and high-speed conveyors.

• Packaging Machinery: Coordinated motion for bottling, wrapping, and labeling lines.

• Robotics: Multi-axis articulated arms or Cartesian robots requiring synchronized precision.

• Hoists and Elevators: High-torque lifting and lowering applications.
