Schneider VW3E1118R020 Servo Hybrid Cable Assembly, 2m

Description

Schneider VW3E1118R020 Servo Hybrid Cable Assembly, 2m

The Schneider Electric VW3E1118R020 is a specialized, pre-assembled hybrid cable designed for use within Schneider’s PacDrive 3 motion control system. It belongs to the accessories line for Lexium iSH integrated servo drives and Distribution Boxes (DB).

Product Detailed Description

The VW3E1118R020 is a 2-meter long hybrid cable designed to connect a Distribution Box (DB) to a Lexium iSH integrated servo drive (or connect Distribution Boxes together) in a distributed motion control architecture. Instead of running separate power, control, and communication cables to every motor, this single hybrid cable carries both motor power and DC bus/communication lines, dramatically simplifying multi-axis machine wiring.

Technical Parameters

Product Advantages

• Hybrid Efficiency: Combines power and communication into a single cable assembly, reducing installation time, cabinet space, and wiring complexity by up to 50%.
• Pre-Assembled Reliability: Factory-molded industrial connectors eliminate wiring errors, short circuits, and poor pin contacts common in field-assembled cables.
• Optimized for Motion: Designed with high flexibility to withstand flexing, oil exposure, and harsh mechanical conditions typical in automated packaging or assembly machinery.
• Quick-Lock Connectors: Features robust industrial connectors that allow fast, secure, tool-free plugging and unplugging during maintenance.

Important Considerations & Precautions

• Bending Radius: Observe the specified minimum static and dynamic (drag-chain) bending radii. Over-bending can damage internal shielding or cause intermittent communication loss.
• Cable Length (R020): This model is strictly 2 meters long. Always measure the distance between the Distribution Box and the Lexium iSH drive before installation; chaining modified adapters is not recommended.
• Connector Cleanliness: Keep the multi-pin connector faces clean and free of dust, conductive metal filings, or liquids before mating.
• Power Down Before Servicing: Never connect or disconnect the cable while the PacDrive system or DC bus is powered, as arcing can damage the delicate connector pins.

Product Applications

The VW3E1118R020 is typically used in multi-axis, decentralized motion control applications:

• Packaging Machinery: Distributed servo motor wiring in high-speed cartoners, wrappers, and labeling machines.
• Material Handling & Robotics: Connecting decentralized drives along gantry systems or conveyor transfer stations.
• Food & Beverage Lines: Interfacing servo drives in bottling, filling, and processing automation where compact, sealed wiring is required.
• General OEM Automation: Any PacDrive 3 system relying on Lexium iSH integrated motors and Distribution Boxes.
