SCHNEIDER LE1M35U716 Enclosed DOL Motor Starter

Description

SCHNEIDER LE1M35U716 Enclosed DOL Motor Starter

The Schneider Electric LE1M35U716 is a pre-wired, enclosed Direct-On-Line (DOL) motor starter belonging to the TeSys LE1M series. It combines a contactor and a thermal overload relay inside a durable polycarbonate enclosure, equipped with integrated pushbuttons (Start/Stop) and an operation indicator light.

Designed for 3-phase asynchronous motor control, it provides complete local control along with overcurrent and phase-loss protection.

Technical Specifications

Key Advantages

• Plug-and-Play Integration: Pre-wired internally to significantly reduce installation time and potential wiring errors.
• Robust Environmental Protection: The IP65-rated enclosure guards against water jets, dust particles, and harsh industrial surroundings.
• Comprehensive Motor Protection: Integrated thermal overload protection prevents motor damage caused by mechanical overloads or phase failures.
• Compact Footprint: Combines control and protection components into a compact housing ideal for wall mounting in space-constrained areas.
• Clear User Feedback: Features distinct color-coded pushbuttons and an illuminated indicator light for visual status verification.

Important Usage & Installation Precautions

• Current Range Matching: Verify that the connected motor’s Full Load Current (FLC) falls strictly within the 8.0 A to 11.5 A adjustable range. Adjust the dial on the internal thermal overload relay before energizing.
• Coil Voltage Check: Ensure the control circuit supply voltage strictly matches 240 V AC. Applying incorrect control voltage can burn out the coil or cause failure to latch.
• Short-Circuit Protection: The thermal overload relay only protects against overload currents. Upstream branch circuit protection (molded case circuit breaker or suitable fuses) must be installed to handle short-circuit faults.
• Cable Gland Sealing: Maintain the IP65 rating by using correctly sized IP65-rated cable glands at the knockout entries to prevent moisture and dust ingress.
• Safety Isolation: Always disconnect the main power supply before opening the enclosure cover for maintenance or dial adjustment.

Applications

• Pumps & Fluid Handling: Direct control and protection for centrifugal pumps, submersible pumps, and booster systems.
• HVAC & Ventilation: Driving industrial exhaust fans, air supply blowers, and air handling units (AHUs).
• Material Handling & Conveyors: Machine-side motor control for belt conveyors, small hoists, and sorting equipment.
• General Industrial Machinery: Drives for mixers, small compressors, saws, drills, and packaging machinery.
