SCHNEIDER LE1M35U714 Enclosed DOL Motor Starter

Description

SCHNEIDER LE1M35U714 Enclosed DOL Motor Starter

Technical Overview

The Schneider Electric LE1M35U714 is an enclosed TeSys LE direct-on-line (DOL) starter designed for controlling and protecting 3-phase electric motors up to 5.5 kW at 400 V AC. It features an integrated thermal-magnetic motor circuit breaker (TeSys Frame Size 2 / GV2ME series type) housed inside an IP65 polycarbonate enclosure, complete with an ON/OFF rotary operator handle.

Technical Specifications

Key Product Advantages

• All-in-One Solution: Combines local manual control, motor switching, short-circuit protection, and adjustable overload protection in a single compact unit.
• High Environmental Resistance: The IP65 rating ensures complete protection against dust ingress and low-pressure water jets, making it suitable for tough industrial environments.
• Easy Thermal Adjustment: The internal thermal trip current can be fine-tuned via a dial between 9.0 A and 14.0 A to match exact motor nameplate ratings.
• Enhanced Safety: Features a lockable rotary handle in the OFF position to facilitate safe maintenance and prevent unauthorized operation (LOTO compatible).
• Compact Footprint: Saves control panel space by providing local isolation and protection right at the motor location.

Important Considerations & Usage Notes

• Control Coil Match: Ensure the control circuit supply voltage strictly matches the 240 V AC coil specification.
• Motor Full Load Current (FLC): Verify that your motor’s rated operating current falls within the 9.0–14.0 A range. Selecting an undersized or oversized starter will lead to improper tripping or lack of overload protection.
• Environmental Limits: Do not expose the enclosure to continuous ambient temperatures above +40°C without derating, or below -5°C.
• Cable Gland Installation: Use properly rated IP65 cable glands during wiring to preserve the dust- and moisture-proof seal of the enclosure.

Primary Applications

• Pumps & Fluid Handling: Direct control for water supply, sewage, and agricultural irrigation pumps.
• HVAC Systems: Industrial exhaust fans, ventilation units, and small air handling equipment.
• Material Handling & Processing: Small conveyors, agitators, mixers, crushers, and packaging machinery.
• Workshop Machinery: Woodworking tools, drills, compressors, and small machine tools requiring local DOL switching.
