Schneider DL1BDM8 BA15d Lamp Holder Yellow LED Indicator Bulb

Description

Schneider DL1BDM8 BA15d Lamp Holder Yellow LED Indicator Bulb

The Schneider Electric DL1BDM8 is a high-quality Protected LED Bulb specifically designed for use with the Harmony XB4 (metal) and Harmony XB5 (plastic) series of signaling units. It serves as a reliable, long-lasting light source for illuminated pushbuttons, selector switches, and pilot lights.

Product Detailed Description

The DL1BDM8 is an accessory light block component featuring an integral LED with a BA9s base. Unlike standard incandescent bulbs, this LED unit is “protected,” meaning it is engineered to handle voltage fluctuations and electrical noise common in industrial power supplies, ensuring a stable and consistent light output.

Technical Parameters

Product Advantages

• Exceptional Longevity: With a service life of 100,000 hours, it significantly reduces maintenance costs and downtime compared to traditional filament bulbs.
• Energy Efficiency: Consumes very low current (\le 14 mA), making it ideal for large-scale control panels with many indicators.
• Vibration Resistance: As a solid-state light source, it is highly resistant to the mechanical shocks and vibrations typically found on industrial machinery.
• Instant Illumination: Reaches full brightness immediately upon powering up, providing clear and instantaneous status feedback to operators.

Important Considerations & Precautions

• Voltage Sensitivity: This specific model is rated for 230–240 V AC. Applying a lower voltage will result in dim lighting or no light, while overvoltage may shorten the LED’s lifespan.
• Color Matching: For the best visual clarity, it is recommended to use the Yellow LED (DL1BDM8) with a yellow or clear lens cap. Using a different colored lens (e.g., blue) will significantly reduce the light intensity.
• Mounting: Ensure the BA9s base is fully seated and locked into the socket to maintain a reliable electrical connection in high-vibration environments.

Product Applications

The DL1BDM8 is widely used in control interface applications across various industries:

• Industrial Control Panels: Status indication for “Warning” or “Standby” modes on machinery.
• Power Distribution: Indicating the presence of voltage or phase status in electrical switchboards.
• Material Handling: Signaling the operational status of conveyors or automated sorting systems.
• Food & Beverage: Used in wash-down areas when paired with the high-IP-rated Harmony XB5 plastic series.
