Schneider DL1BDM5 BA15d Lamp Holder Red LED Indicator Bulb

Description

Schneider DL1BDM5 BA15d Lamp Holder Red LED Indicator Bulb

The Schneider Electric DL1BDM5 is a high-quality LED bulb designed specifically for use with industrial signaling units, such as the Harmony XVB, XVP, and XVD tower lights or beacon series. It features a BA15d base (bayonet fitting) and is engineered for long-term reliability in harsh environments.

Product Detailed Description

The DL1BDM5 belongs to the Harmony signaling range. It is a Protected LED bulb that provides a steady light source. Its primary function is to replace traditional incandescent bulbs in industrial indicator banks to reduce power consumption and eliminate frequent maintenance.

Technical Parameters

Product Advantages

• Ultra-Long Lifespan: With a service life of up to 100,000 hours, it significantly outlasts traditional filament bulbs, reducing the “Total Cost of Ownership” (TCO) by minimizing labor for bulb changes.
• Energy Efficiency: Consumes only 14 mA, making it ideal for large-scale installations where reducing energy waste and heat dissipation in control cabinets is a priority.
• Vibration Resistance: Unlike incandescent filaments that break under mechanical stress, the solid-state LED design is highly resistant to industrial vibrations and shocks.
• High Visibility: Provides a clear, bright orange light that ensures machine status is visible even in high-ambient-light factory environments.

Important Considerations (Precautions)

• Voltage Compatibility: This specific model is rated for 230 V AC. Using it with 24 V or 110 V systems will result in either no light or permanent damage to the LED circuitry.
• Color Matching: For the best visual results, it is recommended to use an orange LED bulb (DL1BDM5) with an orange signaling lens. Using a white LED behind a colored lens may result in a washed-out or incorrect color hue.
• Polarity: While designed for AC, ensure the bayonet base is seated correctly in the socket to maintain a consistent electrical connection in high-vibration areas.

Product Applications

The DL1BDM5 is widely used in signaling and notification systems:

• Tower Lights (Stack Lights): Used in Harmony XVB towers on CNC machines and assembly lines to indicate a “Warning” or “Minor Error” status.
• Industrial Beacons: Integrated into standalone revolving or steady beacons for safety signaling.
• Control Panels: Used in large-diameter pilot lights that require a BA15d fitting for status indication.
• Material Handling: Installed on conveyor systems to signal operational transitions or caution.
