Schneider 499NTR10100 Copper Transceiver Module

Description

Schneider 499NTR10100 Copper Transceiver Module

The Schneider Electric 499NTR10100 is a high-grade Industrial Ethernet Copper Port Transceiver (Media Converter) from the ConneXium product family. It is specifically designed to provide robust, reliable fiber-to-copper or copper-to-copper connectivity within harsh industrial automation environments.

Product Detailed Description

The 499NTR10100 is a modular transceiver designed to be plugged into ConneXium managed or unmanaged switches. Its primary role is to serve as an interface between the network switch and the physical Ethernet cabling. It is built to withstand extreme temperatures and electromagnetic interference (EMI), ensuring that data transmission remains stable in factory-floor conditions.

Technical Parameters

Product Advantages

• Industrial Hardening: Unlike commercial-grade transceivers, this module is “hardened” to handle the high vibration and wide temperature fluctuations found in industrial cabinets.
• Plug-and-Play: Requires no software configuration; the host switch automatically recognizes the transceiver and negotiates the optimal speed and duplex settings.
• Compact Form Factor: Its small size allows for high-density port configurations within ConneXium switches without significantly increasing the footprint.
• Seamless Compatibility: Fully optimized for the Schneider Electric EcoStruxure architecture, ensuring seamless communication between PLCs, HMIs, and SCADA systems.

Important Considerations (Precautions)

• Shielding: To maintain the rated EMI/RFI resistance, it is highly recommended to use Shielded Twisted Pair (STP) cables with high-quality RJ45 connectors.
• Host Compatibility: Ensure that your ConneXium switch model supports the 499 series transceivers. While many are universal, some older racks may have specific slot restrictions.
• Bending Radius: When routing the Ethernet cable from the 499NTR10100, do not exceed the cable’s minimum bending radius, as this can cause signal degradation and “packet loss.”
• ESD Protection: Always ground yourself before touching the module pins to prevent Electrostatic Discharge (ESD) damage to the sensitive internal circuitry.

Product Applications

The 499NTR10100 is typically used in large-scale industrial networking projects:

• Control Cabinet Networking: Providing the physical connection between a core backbone switch and local devices like Modicon PLCs or Altivar Drives.
• Distributed I/O Systems: Connecting remote I/O drops to the main control network over standard copper Ethernet cabling.
• HMI Interfacing: Facilitating high-speed data exchange between industrial PCs (iPCs) and the control layer.
• Manufacturing Lines: Used in assembly line networks where reliable 10/100 Mbps communication is required despite electrical noise from motors and welders.
