Schneider 1405DO95300S 16-Channel Digital Safety Output Module

Brand: Schneider

Model number:1405DO95300S

Colour:new                                    Warranty: 12 months

Lead Time:3-day working day   Country of origin: France

Price: Please contact us         Product weight:0.5kg

Category: SKU: 1405DO95300S Brand:

Description

Schneider 1405DO95300S 16-Channel Digital Safety Output Module

The Schneider Electric 140DDO35300S (often referred to under the Modicon Quantum legacy brand) is a high-density Digital Output Module. It is a cornerstone of the Quantum automation platform, designed to interface between the PLC and various industrial actuators.



Product Detailed Description

The 140DDO35300S is a 32-Channel Source Digital Output Module. It operates on a 24 V DC logic level and is designed to switch external loads such as solenoids, relays, and motor starters. The “S” suffix typically indicates a specific hardware revision or “Source” logic (where the module provides the positive voltage to the load).

Technical Parameters

Feature Specification
Product Series Modicon Quantum
Module Type Digital Output (Discrete)
Number of Channels 32
Logic Type Source (Positive Logic)
Rated Voltage 24 V DC
Operating Voltage Range 19.2 V to 30 V DC
Output Current 0.5 A per channel (Max 12 A per module)
Response Time < 1 ms (Off to On / On to Off)
Isolation 500 Vrms for 1 minute (between channels and bus)
Power Dissipation 2.5 W + (0.4 W \times number of outputs on)



Product Advantages

  • High Density: With 32 channels in a single slot, it maximizes the I/O capacity of a Quantum rack, making it ideal for large-scale industrial projects with limited cabinet space.
  • Internal Diagnostics: Features front-panel LED indicators for each channel, allowing maintenance personnel to quickly verify the status of every output and detect faults at a glance.
  • Rugged Reliability: Built specifically for harsh industrial environments, featuring high electromagnetic compatibility (EMC) and vibration resistance.
  • Modular Integration: Fully compatible with all Modicon Quantum CPUs and distributed I/O (RIO/DIO) drops, ensuring seamless communication within the EcoStruxure architecture.



Important Considerations & Precautions

  • External Power: The module requires an external 24 V DC power supply to drive the output loads. Ensure this supply is properly fused to protect the module’s internal circuitry.
  • Current Limits: While each channel can handle 0.5 A, the total current for the entire module must not exceed 12 A. Overloading the module can lead to overheating and permanent hardware failure.
  • Inductive Loads: When switching inductive loads (like large solenoid valves), it is highly recommended to use external suppression devices (diodes or RC snubbers) to prevent back-EMF from damaging the output transistors.
  • Hot-Swapping: While the Quantum rack supports “Hot Standby,” always verify the specific backplane and CPU configuration before attempting to swap the module while the system is energized.



Product Applications

  • Process Automation: Controlling banks of solenoid valves and actuators in chemical processing or water treatment plants.
  • Manufacturing: Managing pneumatic cylinders, grippers, and conveyor diverters on high-speed assembly lines.
  • Power Distribution: Operating trip and close coils for low-voltage breakers in automated power management systems.
  • Material Handling: Signaling for stacker cranes and automated guided vehicles (AGVs) in large warehouses.
