Omron S820-6024 Switching Power Supply

Description

Omron S820-6024 Switching Power Supply

Product Dimensions：

The Omron S82D-6024 (often part of the broader S82 series) is a classic, high-reliability Switch Mode Power Supply (SMPS) designed for industrial DIN-rail mounting. It is engineered to provide a stable DC voltage to sensitive automation components like PLCs, sensors, and HMI panels.

Product Detailed Description

The S82D-6024 is a compact, enclosed power supply that converts standard AC utility power into a regulated 24V DC output. Known for its rugged construction, it was a staple in industrial control panels for decades before being succeeded by the S8FS and S8VK series. It features a robust metal casing that provides excellent heat dissipation and electromagnetic shielding.

Technical Parameters

Product Advantages

• Stable Output: Provides low ripple and noise, ensuring that electronic controllers and sensors operate without interference or “ghost” signals.
• Industrial Durability: Designed to handle the harsh electrical environments of factories, including voltage fluctuations and high-frequency noise.
• Compact Footprint: The slim design allows for efficient use of space within crowded electrical control cabinets.
• Safety Certifications: Usually carries UL, CSA, and CE markings, ensuring compliance with global safety standards for industrial equipment.

Important Considerations & Precautions

• Ventilation: Maintain at least 20mm of clearance above and below the unit. These units rely on natural convection cooling; blocking the vents can lead to thermal shutdown or reduced lifespan.
• Output Adjustment: When using the voltage trimmer to increase the voltage beyond 24V, ensure the total output power does not exceed 60W (e.g., at 26V, the max current is lower than 2.5A).
• Wiring: Use the correct wire gauge for 2.5A to prevent voltage drops. Ensure all terminal screws are tightened to the specified torque to avoid arcing.
• End-of-Life: Since this is an older series, if the unit fails, it is often recommended to replace it with a modern equivalent like the S8VK-G06024, which offers higher efficiency and better vibration resistance.

Product Applications

• PLC Power: Providing the main logic power for Omron CPM, CJ, or CS series PLCs.
• Sensor Arrays: Powering 24V DC photoelectric, inductive, or capacitive proximity sensors.
• Relay Logic: Driving the coils of industrial relay sequences and timers.
• Small Actuators: Supplying power to small DC solenoid valves or indicator lamps in a control panel.
