NI PXIE-6363 I/O Module

Description

NI PXIE-6363 I/O Module

The NI PXIe-6363 is a high-performance multifunction Data Acquisition (DAQ) module from National Instruments, part of the X Series family. It is designed for high-speed synchronization and high-throughput data transfer using the PXI Express bus.

1. Product Overview

The NI PXIe-6363 provides a combination of analog I/O, digital I/O, and counter/timer functionality in a single 3U PXI Express module. It utilizes NI-STC3 timing and synchronization technology, which offers advanced flexibility for complex triggering and high-speed data streaming.

2. Technical Specifications

Below are the key parameters for the NI PXIe-6363:

3. Key Advantages

• High Throughput: Leveraging the PXI Express bus, it provides significantly higher bandwidth than standard PCI or PXI, making it ideal for high-channel-count data streaming.

• NI-STC3 Technology: Features independent timing engines for analog and digital I/O, allowing for different sampling rates across various subsystems.

• Multithreaded Driver: Works seamlessly with NI-DAQmx driver software, which simplifies programming with features like configuration-based tasks and optimized DMA (Direct Memory Access).

• Seamless Integration: Fully compatible with LabVIEW, MATLAB, and C/.NET environments.

4. Important Considerations (Usage Notes)

• Cooling Requirements: Ensure the PXIe chassis has adequate airflow, as high-performance X Series modules can generate significant heat during high-speed operations.

• Connector Type: Uses two 68-pin VHDCI connectors. You will need compatible cables (e.g., SHC68-68-EPM) and connector blocks (e.g., SCB-68A).

• Grounding: Pay close attention to the difference between Single-Ended (RSE/NRSE) and Differential (DIFF) configurations to avoid ground loops or noise interference.

• Synchronization: If using multiple modules, ensure you are utilizing the PXIe backplane triggers for sub-nanosecond synchronization.

5. Product Applications

The versatility of the PXIe-6363 makes it a staple in various industries:

• Aerospace & Defense: High-speed sensor recording and structural health monitoring.

• Automotive Testing: Real-time HIL (Hardware-in-the-Loop) simulation and ECU testing.

• Scientific Research: High-resolution physics experiments and material characterization.

• Manufacturing: Automated Test Equipment (ATE) for high-volume production lines.
