NI CRI0-9063 Redundant Power Supply Module

Description

NI CRI0-9063 Redundant Power Supply Module

The NI cRIO-9063 (CompactRIO Controller) is an embedded industrial controller designed by National Instruments. It is widely recognized for its high performance, ruggedness, and flexibility in demanding environments.

Below is the detailed documentation for the NI cRIO-9063.

1. Product Description

The cRIO-9063 is a member of the CompactRIO family, featuring a Zynq-7000 All Programmable SoC from Xilinx. This architecture combines a dual-core ARM Cortex-A9 processor with a 7-series FPGA on a single chip. It is designed for low-power consumption and high-reliability applications, running the NI Linux Real-Time operating system.

2. Technical Specifications

The cRIO-9063 is a 4-slot chassis-integrated controller. Key hardware parameters include:

3. Product Advantages

• Integrated Architecture: Combining a processor and FPGA allows for high-speed control loops and hardware-timed signal processing without the latency of a separate bus.

• NI Linux Real-Time: Offers the openness of a Linux ecosystem combined with the determinism required for industrial control.

• Rugged Design: Built to withstand high vibrations (5g) and shocks (50g), making it ideal for deployment in harsh industrial or mobile environments.

• Vast I/O Ecosystem: Compatible with over 100 NI C Series modules for various sensors (analog, digital, motion, automotive bus, etc.).

• Software Productivity: Programmable via LabVIEW, C/C++, or Python, significantly reducing development time.

4. Key Considerations & Precautions

• Thermal Management: Ensure adequate space around the cooling vents. If used in high-temperature environments, forced air cooling may be necessary.

• Power Supply: Use a reliable 9 V to 30 V DC power source. Ensure the power supply can handle the peak current requirements of all inserted modules.

• Grounding: Properly ground the chassis to prevent EMI (Electromagnetic Interference) and protect the internal circuitry.

• Module Compatibility: While most C Series modules are supported, always verify the specific module’s driver support for the NI Linux Real-Time OS.

5. Applications

The cRIO-9063 is versatile and used across various industries:

• Industrial Control: High-speed machine control and complex motion synchronization.

• Condition Monitoring: Real-time analysis of vibration and sound for predictive maintenance in power plants or heavy machinery.

• Smart Grid: Monitoring and controlling power quality in electrical substations.

• Automotive Testing: In-vehicle data logging and rapid control prototyping (RCP).

• Embedded Academic Research: Developing advanced robotics or biomedical instrumentation.
