KRIES CAPDIS-S2 Capacitive Voltage Detection System

Description

KRIES CAPDIS-S2 Capacitive Voltage Detection System

Product Dimensions：

The Kries CAPDIS-S2 (and the enhanced CAPDIS-S2+) is a sophisticated Integrated Voltage Detecting System (VDS) designed for high and medium-voltage switchgear. It provides continuous three-phase voltage monitoring and is used to confirm the absence of voltage safely, according to international standards like IEC 61243-5 and IEC 62271-213.

Below is the detailed product information in English.

1. Product Description

The CAPDIS-S2 series consists of maintenance-free voltage detectors that do not require an external battery for their primary function. While the CAPDIS-S1 is a basic indicator, the S2 version includes integrated relay contacts for remote signaling and control functions, making it suitable for interlocking and automation within smart grid environments.

2. Technical Specifications

3. Key Advantages

• Maintenance-Free: Permanent self-monitoring and “Fail-Safe” design eliminate the need for periodic manual testing.

• No Battery Required: Voltage detection and self-testing functions work without external power or batteries.

• Integrated Self-Test: Features a built-in test button to verify the functionality of the display and electronic circuits.

• Smart Grid Ready: Includes interfaces (Y-interface) for connecting to direction-sensing relays (e.g., IKI-50) and monitoring systems.

• Inherent Safety: Provides “Broken Lead Detection” (optional/switchable) to distinguish between actual voltage absence and a cable fault.

• Insulation Monitoring: Continuously monitors the health of the capacitive divider.

4. Product Applications

• Medium and High-Voltage Switchgears: Used as a primary safety device to check for voltage absence before maintenance.

• Remote Monitoring: The relay outputs allow integration into SCADA systems for real-time status updates.

• Interlocking Systems: Used to prevent accidental grounding or switching operations when voltage is still present.

• Partial Discharge (PD) Detection: Newer R5 versions include PD detection to provide early warning of insulation degradation.

5. Precautions & Important Notes

• Configuration: During ordering, the rated operating voltage ($U_n$) and the coupling capacitance ($C_1$) of the insulators must be specified to ensure the device is correctly calibrated.

• Auxiliary Power: While the visual indication works without power, the relay outputs and status LEDs require the auxiliary supply (24-230V AC/DC) to function.

• Phase Comparison: Only use the integrated 3-phase test point (LRM interface) with compatible testers (like CAP-Phase) for phase sequence or comparison tests.

• Installation: Ensure the device is mounted in a dry, dust-free environment or within a housing that meets the required IP rating for the specific site.
