GE SRPG600A600 Circuit Breaker Rating Plug

Description

GE SRPG600A600 Circuit Breaker Rating Plug

Product Overview

The GE / ABB SRPG600A600 is an interchangeable rating plug designed for GE Spectra RMS™ Molded Case Circuit Breakers equipped with solid-state electronic trip units (such as MicroVersaTrip™ Plus and MicroVersaTrip™ PM).

Plugging directly into an SG-600 frame circuit breaker (such as SEDA, SEHA, SELA, or SEPA), this module establishes the breaker’s continuous current rating (I_n) at 600 Amperes without needing to replace the entire circuit breaker frame.

Technical Specifications

Key Advantages

• Cost-Effective System Sizing: Adjusts or upgrades the circuit breaker’s continuous load rating to 600 A without the expense and labor of replacing the full circuit breaker unit or busbar connections.
• Tool-Free Field Installation: Features a simple plug-in interface into the front face of the electronic trip unit for quick maintenance and system reconfiguration.
• High Trip Accuracy: Integrates seamlessly with RMS sensing microprocessors to provide precise long-time overload and short-time/instantaneous fault protections.
• Reliable Rejection Pinning: Mechanical keying prevents installation of incorrect rating plugs that do not match the breaker frame’s physical and electrical capacity.

Important Installation & Usage Precautions

• De-Energize System First: Always disconnect, isolate, and lock out all upstream electrical power before inserting, removing, or replacing the rating plug inside the circuit breaker.
• Frame & Sensor Matching: The SRPG600A600 plug must only be used with SG-600 frame circuit breakers fitted with a 600 A current sensor. It is not cross-compatible with smaller (SF, SE) or larger (SK) Spectra frames.
• Proper Seating: Ensure the plug is fully pushed into the trip unit receptacle until locked securely; improper contact can trigger false trip conditions or loss of protection.
• Downstream Protection Coordination: Modifying the rating plug changes the primary trip settings (I_n). Verify that downstream cables, switchboards, and loads are rated to safely handle up to 600 A continuously.

Primary Applications

• Commercial & Industrial Switchboards: Power distribution panels in manufacturing facilities, high-rise buildings, and processing plants.
• Motor Control Centers (MCC): Feeder circuit breaker protection for high-capacity motor control branch circuits.
• Facility Retrofits & System Upgrades: Easily scaling up power distribution capacity when system loads increase to 600 A.
