GE IC695CBL002A Connection Cable
Product Dimensions:
The GE Fanuc / Emerson IC695CBL002A is a high-performance Serial Cable designed specifically for the PACSystems RX3i control system. It provides a reliable physical link for RS-232 serial communication between the RX3i CPU (via the RJ-45 serial port) and external devices like PCs, HMIs, or other industrial controllers.
Technical Specifications
The following table outlines the primary hardware specifications:
| Parameter | Specification |
| Product Series | PACSystems RX3i |
| Model Number | IC695CBL002A (Revision A) |
| Connector A | RJ-45 (Plugs into the RX3i CPU/Module) |
| Connector B | 9-pin D-sub (Female) (Plugs into PC/Peripheral) |
| Communication Type | RS-232 |
| Length | Approximately 3 Meters (9.8 Feet) |
| Shielding | Fully shielded to prevent EMI/RFI interference |
Product Advantages
-
Plug-and-Play Compatibility: Specifically designed for the RX3i platform, ensuring immediate recognition and stable signal transmission without custom wiring.
-
Robust Shielding: Built with high-quality industrial-grade materials to withstand the electrical noise (EMI) common in factory floor environments.
-
Secure Connection: The RJ-45 latch and D-sub thumb screws ensure the cable remains connected even in high-vibration settings.
-
Standard Length: The 3-meter length provides sufficient reach for local programming and troubleshooting from a laptop or workstation.
Important Considerations (Usage Notes)
-
Port Identification: This cable is intended for the RS-232 port on the RX3i CPU. Do not attempt to force it into an Ethernet (RJ-45) port, as this may cause electrical damage to the communication hardware.
-
Power Safety: While the cable is designed for hot-swapping in many cases, it is best practice to ensure the ground potential of the connected PC and the PLC are the same to avoid ground loops.
-
Baud Rate Limits: Being an RS-232 cable, it is subject to standard serial distance/speed limitations. Ensure your software configuration matches the hardware port settings (e.g., 9600, 19200, or 115200 bps).
Typical Applications
-
PLC Programming: Connecting a laptop running Proficy Machine Edition to the RX3i CPU for logic uploads, downloads, and monitoring.
-
Firmware Upgrades: Necessary for flashing new firmware to the RX3i controller modules via the serial loader.
-
HMI Interfacing: Connecting older or specialized Human Machine Interfaces that require a direct serial RS-232 link for data exchange.
-
Diagnostics: Local system debugging when network/Ethernet access is restricted or unavailable.
