GE IC200CHS022J 12-Slot Rack

Description

GE IC200CHS022J 12-Slot Rack

Product Dimensions：

The GE IC200CHS022J is a high-density I/O Carrier part of the VersaMax family from GE Fanuc (now maintained under Emerson Automation Solutions). It is a fundamental component used to provide the physical and electrical interface for I/O modules.

Product Detailed Description

The IC200CHS022J is a Compact Terminal-Style I/O Carrier. Its primary role is to mount VersaMax I/O modules onto a DIN rail. Unlike standard carriers, the “Compact” version is designed to save cabinet space while providing a structured interface for field wiring.

It supports up to 32 points of field wiring and includes an integrated interposing terminal strip. The “J” suffix indicates the latest hardware revision, ensuring compatibility with modern firmware and improved manufacturing standards.

Technical Specifications

Key Product Advantages

• Space Efficiency: The compact footprint allows for high-density I/O configurations in restricted control panels.

• Ease of Maintenance: Modules can be replaced without disturbing the field wiring, significantly reducing downtime during repairs.

• Rugged Design: Built to withstand industrial environments, offering reliable mechanical latching for I/O modules.

• Versatility: Compatible with a wide range of VersaMax discrete and analog I/O modules.

• Simple Wiring: The box-style terminals provide secure connections for various wire gauges without the need for specialized tools.

Important Usage Considerations (Precautions)

1. Hot Swapping: While the carrier supports module removal, always ensure the specific I/O module and PLC CPU firmware support “Hot Swapping” before attempting to remove a module under power.

2. Wiring Clearance: Maintain adequate clearance for field wiring to prevent stress on the terminal blocks.

3. Torque Settings: Do not over-tighten the terminal screws; follow the manufacturer’s recommended torque specs (typically 0.5 Nm) to avoid stripping threads.

4. ESD Protection: Handle the carrier and attached modules with proper grounding to prevent Electrostatic Discharge (ESD) damage to the internal backplane.

Product Applications

The IC200CHS022J is widely used in automated systems across various industries:

• Water/Wastewater: Monitoring sensors and controlling pumps in treatment plants.

• Packaging Machinery: High-speed I/O processing for sorting and wrapping.

• Oil & Gas: Interfacing with field instrumentation in remote terminal units (RTUs).

• Building Automation: Controlling HVAC systems and lighting circuits.
