Eaton E50KL201 Solid State Relay

Description

Eaton E50KL201 Solid State Relay

Product Dimensions：

The Eaton E50KL201 is a high-performance operating lever designed for use with the E50 Heavy-Duty Plug-In Limit Switch series. It serves as the physical interface that interacts with moving machinery to actuate the internal electrical contacts of the switch.

Product Detailed Description

The E50KL201 is an adjustable roller lever operating head attachment. It features a nylon roller and a mechanism that allows the length of the lever arm to be adjusted. This adjustability is crucial for fine-tuning the trip point of the limit switch based on the physical constraints and positioning of the machinery or targets it is monitoring.

It is designed to seamlessly mount onto E50 side-rotary limit switch operating heads.

Technical Parameters

Product Advantages

• High Adjustability: The variable arm length allows engineers to optimize mechanical leverage and adapt the switch to varying machine tolerances without moving the entire switch housing.
• Heavy-Duty Construction: Built to withstand the rigorous demands of industrial environments, offering high resistance to mechanical shock and vibration.
• Nylon Roller Benefits: The nylon roller provides smooth operation, reduces wear on the machinery targets passing over it, and offers excellent resistance to corrosion and chemical exposure.
• Flexible Cam Operation: Can be configured to actuate the switch when rotated clockwise, counterclockwise, or in both directions depending on the E50 head setting.

Important Considerations & Precautions

• Tightening Torque: Ensure the clamp screw securing the lever to the operating head shaft is tightened to the manufacturer’s specified torque. A loose lever can slip, causing a failure to actuate.
• Overtravel Limits: Do not allow the machinery target to push the lever beyond its maximum allowed overtravel angle, as this can permanently damage the internal clock springs of the operating head.
• Roller Wear: Periodically inspect the nylon roller for flat spots or cracks, especially in high-cycle applications, to prevent sticking or irregular actuation.
• Compatibility: This lever is specifically engineered for the Eaton E50 series and may not fit securely on third-party limit switch shafts or older, discontinued lineages.

Product Applications

The E50KL201 lever is utilized across automated production lines and heavy machinery where precise position detection is required:

• Conveyor Systems: Detecting the presence, alignment, or passing of large packages, crates, or pallets.
• Automotive Assembly: Tracking the position of overhead carriers, robotic arm boundaries, or indexing tables.
• Material Handling: Acting as a safety interlock or travel limit on hoists, cranes, and automated storage/retrieval systems (ASRS).
• Packaging Machinery: Coordinating the timing of folding mechanisms, gates, and sorting arms.
