B&R X20CP1483 Processor Module
Product Dimensions：
The B&R X20CP1483 is a high-performance, compact Standard CPU module from B&R Industrial Automation’s versatile X20 System family. It is widely used in mid-to-high-end machine automation and process control due to its processing power, integrated communication interfaces, and modular expansion capabilities.
Product Detailed Description
The X20CP1483 serves as the central control hub for an automation system. It combines an Intel Celeron processor with a variety of integrated interfaces into a small footprint. It is designed to slide directly onto an X20 backplane, allowing for seamless connection to local X20 I/O modules, while its embedded Ethernet and USB ports connect the controller to upper-level SCADA systems, HMIs, or network drives.
Technical Parameters
| Feature | Specification |
| Product Series | B&R X20 System |
| Processor | Intel Celeron 200 MHz (or compatible architecture) |
| System Memory | 64 MB DDR SDRAM |
| User Memory | 32 MB onboard Flash drive |
| Integrated Interfaces | 1x RS232, 1x Ethernet (10/100 Mbit/s), 1x USB 2.0 |
| Fieldbus Options | Standard X2X Link (for local I/O expansion) |
| Real-Time Clock (RTC) | Yes, battery-backed |
| Power Consumption | Max. 3.5 W (CPU only) |
| Operating Temperature | 0°C to +55°C |
Product Advantages
- High Performance-to-Size Ratio: Delivers robust processing power for complex logic and basic motion control without requiring a large, bulky control cabinet footprint.
- Automation Studio™ Integration: Fully programmed and configured using B&R Automation Studio, allowing for efficient development in IEC 61131-3 languages (such as Structured Text) or ANSI C.
- Fanless Operation: The efficient hardware design operates without moving parts like cooling fans, significantly reducing mechanical failure rates and maintenance requirements.
- Modular Scalability: The local X2X Link allows users to daisy-chain dozens of standard X20 digital, analog, or functional safety modules directly to the right side of the CPU.
Important Considerations & Precautions
- Memory Management: Ensure the compiled application code, recipe data, and log files do not exceed the 32 MB onboard Flash capacity. Consider optimizing cyclic task classes if memory warnings appear.
- Firmware Synchronization: When deploying or replacing a CPU, ensure the Automation Runtime (AR) version on the controller matches the project requirements compiled in Automation Studio.
- Backup Battery: The real-time clock and retentive variables depend on an internal battery. Monitor system diagnostics for “battery low” status to prevent loss of retentive data during power outages.
- ESD & Hot-Plugging: Always power down the system before attaching or detaching local I/O modules from the CPU assembly to avoid Electrostatic Discharge (ESD) damage to the backplane.
Product Applications
The X20CP1483 is a versatile controller utilized across numerous automated sectors:
- Packaging Machinery: Controlling high-speed wrapping, sorting, and labeling machines.
- Plastics & Injection Molding: Managing temperature zones, hydraulic valves, and clamping sequences.
- Textile Automation: Synchronizing multi-axis spinning, weaving, or dyeing control loops.
- Factory Utilities: Serving as a master controller for localized HVAC, water treatment, or air compressor systems inside manufacturing facilities.
