B&R X20CA0E61.01500 Communication Interface Module
Product Dimensions：
The B&R X20CA0E61.01500 is a specialized system cable from B&R Industrial Automation’s X20 System series. It is primarily designed for high-speed data transmission and connectivity between X20 controllers, bus receivers, and expansion modules.
Product Specifications (Parameters)
| Feature | Details |
| Model Number | X20CA0E61.01500 |
| Product Type | X2X Link Expansion Cable |
| Length | 15.0 meters |
| Connection A | X2X Link male connector |
| Connection B | X2X Link male connector |
| Communication Protocol | X2X Link (Proprietary B&R high-speed backplane bus) |
| Cable Jacket Material | PUR (Polyurethane) – Oil resistant and halogen-free |
| Shielding | S/STP (Screened Shielded Twisted Pair) for high EMC protection |
| Operating Temperature | -25°C to +80°C (fixed installation) |
Key Product Advantages
-
Seamless Integration: Specifically engineered for the X20 System, ensuring “plug-and-play” compatibility without the risk of communication errors.
-
High Noise Immunity: Features robust shielding to protect data integrity in harsh industrial environments with high electromagnetic interference (EMI).
-
Durability: The PUR outer jacket provides excellent resistance to oils, chemicals, and mechanical wear, making it suitable for demanding factory floors.
-
High-Speed Data: Supports the full bandwidth of the X2X Link protocol, enabling fast cycle times for complex automation tasks.
Important Considerations (Usage Notes)
-
Bend Radius: While PUR is flexible, always observe the minimum permissible bend radius during installation to prevent internal fiber or wire damage.
-
Distance Limitations: This cable is 15 meters long. Ensure that the total X2X Link segment length (including this cable) does not exceed B&R’s maximum specified distance for your specific baud rate.
-
Connection Security: Ensure the connectors are fully seated and clicked into place to maintain the IP protection rating and stable electrical contact.
-
Avoid Parallel Routing: Do not route this data cable directly parallel to high-voltage power lines to prevent inductive interference.
Product Applications
The X20CA0E61.01500 is used wherever X20 modules need to be distributed across different cabinets or machine sections:
-
Distributed I/O: Connecting a main PLC cabinet to remote I/O islands on a large machine.
-
Modular Machinery: Linking different machine modules that need to communicate via the X2X Link backplane.
-
Control Cabinet Links: Bridging communication between two separate control cabinets in a production line.
