AUTOMATIONDIRECT DO-10ND3 Discrete input module

Description

AUTOMATIONDIRECT DO-10ND3 Discrete input module

Product Dimensions：

1. Product Detailed Description

The D0-10ND3 is a versatile DC input module that allows a DL05 or DL06 PLC to receive signals from up to 10 additional field devices. It supports both sinking and sourcing (NPN/PNP) wiring configurations, providing flexibility when connecting different types of sensors. The module features two isolated commons, allowing for the grouping of inputs across different power sources or signal types.

2. Product Parameters (Specifications)

3. Product Advantages

• Flexible Wiring: Supports both NPN (sinking) and PNP (sourcing) field devices, making it compatible with a wide range of industrial sensors.

• Space-Saving: Adds 10 points of I/O in a single option slot, maximizing the capability of the compact DL05/DL06 series.

• Dual Isolation: Two isolated commons allow the module to handle different voltage levels or separate circuits within the same module.

• Easy Maintenance: Features a removable terminal block, allowing for quick module replacement without the need to rewire individual connections.

• Status Monitoring: Includes a green LED for module activity to assist with real-time troubleshooting.

4. Cautions & Precautions

• No Internal Fuses: This module is not equipped with internal fuses. External fusing is recommended to protect the module and field wiring from overcurrent conditions.

• Voltage Limits: Do not exceed the peak voltage of 30.0 VDC, as this may cause permanent damage to the input circuitry.

• Proper Grounding: Ensure the PLC base and the module are properly grounded to a single point to minimize electrical noise and ensure signal integrity.

• Wiring Safety: Always disconnect power before removing or installing the module or the terminal block to avoid electrical shock or equipment damage.

5. Product Applications

The D0-10ND3 is typically used in small-scale automation projects where discrete DC signals need to be monitored:

• Sensor Integration: Connecting proximity switches, photoelectric sensors, and limit switches.

• Machine Logic: Receiving signals from pushbuttons, selector switches, and auxiliary contacts of relays.

• Packaging Machinery: Monitoring product presence or mechanical positions on a conveyor line.

• Material Handling: Small sorting systems or lift station controls.
