Automation Direct EA9-T10WCL HMI Touchscreen

Description

Automation Direct EA9-T10WCL HMI Touchscreen

Product Dimensions：

The AutomationDirect EA9-T10WCL is a 10-inch widescreen touch screen Human-Machine Interface (HMI) from the popular C-more EA9 series. It provides a full-featured operator interface designed for monitoring and controlling automated machinery across various industrial environments.

Product Overview

The EA9-T10WCL features a high-resolution color TFT display with a widescreen 16:9 aspect ratio, giving users expanded screen real estate to build intuitive control screens, display complex visual indicators, and monitor system alarms. Equipped with multiple communication ports, rich software compatibility, and flexible protocol support, it serves as an ideal interface bridging PLCs, motion controllers, drives, and network infrastructure.

Technical Specifications

Key Advantages & Features

• Enhanced Visual Clarity: The 1024×600 resolution combined with LED backlighting provides high contrast, crisp text, and vibrant graphical elements for operators.
• Rich Connectivity Options: Out-of-the-box support for Ethernet, multiple serial channels, and USB connections allows simultaneous communication with various PLC brands (AutomationDirect, Allen-Bradley, Siemens, Omron, Mitsubishi, Modbus, etc.).
• User-Friendly Software: Programmed via the C-more Programming Software, featuring pre-built object libraries, simplified tag management, and easy screen navigation setups.
• Remote Access & Control: Supports web server capabilities, remote access via mobile apps (iOS/Android), email/SMS event notifications, and FTP file transfers for easy remote monitoring.
• Data Logging & Trending: Efficiently records historical trends, alarm event histories, and operator actions directly onto an SD card or USB flash drive.

Important Precautions & Guidelines

• Power Requirements: Ensure a stable, clean 12–24 VDC power supply. Wire power strictly according to polarity to prevent internal circuit damage.
• Environmental Exposure: Designed for NEMA 4/4X indoor applications. Protect the unit from direct sunlight exposure (UV degradation) and ambient temperatures outside its specified operating range (0^{\circ}C to 50^{\circ}C).
• Gasket & Seal Maintenance: To maintain IP65 / NEMA 4X enclosure protection, ensure the panel cutout matches precise dimensions and the sealing gasket is installed without twists or debris.
• Touchscreen Care: Clean the touch surface using soft cloth and mild non-abrasive cleaners. Avoid sharp objects or harsh chemical solvents to prevent damage to the resistive touch membrane.

Primary Applications

• Factory Automation & Assembly Lines: Real-time monitoring of assembly station operations, cycle times, and part counts.
• Packaging Machinery: Screen interface for controlling form-fill-seal machines, labeling equipment, conveyor lines, and pallettizers.
• Water & Wastewater Treatment: Visualization of pump statuses, tank liquid levels, flow rates, and active system alerts.
• HVAC & Building Systems: Supervisory control interface for large commercial air handling units, chillers, and boiler systems.
• Material Handling: System interfaces for automated guided vehicles (AGVs), sorting systems, and automated storage crane controls.
