Arteche BJ8BB Electromagnetic intermediate relays

Description

Arteche BJ8BB Electromagnetic intermediate relays

Product Dimensions：

1. Product Description and Application (产品应用)

The Arteche BJ8BB is a high-speed, high-performance auxiliary/tripping relay. It is designed to act as an intermediary component in complex protection schemes. Its primary function is to multiply the number of contacts available from a primary protection device (like a main protective relay) and to transmit the tripping signal to the circuit breaker’s trip coil.

• Primary Application: Used in protection and control panels within electrical substations, power generation plants, and industrial high-voltage systems.

• Function: Contact multiplication, signal isolation, and guaranteed high-speed operation for circuit breaker tripping.

2. Key Product Parameters (产品参数)

While exact parameters can vary based on the specific variant or order code, here are the typical specifications for the BJ8BB series:

3. Product Advantages (产品优势)

The BJ8BB series is highly regarded in the utility industry for several reasons:

• ⚡ Ultra-Fast Operation: The core advantage is its extremely short operating time (typically $< 5$ ms), which is crucial for minimizing fault duration and preventing equipment damage in a power system.

• High Breaking/Making Capacity: The contacts are robust, designed to reliably handle the high currents and inrush currents associated with tripping a circuit breaker coil.

• High Reliability: Built to stringent standards (like IEC 61810) for long-term dependable performance in harsh substation environments.

• Long Mechanical Life: Engineered for millions of operations, ensuring longevity and low maintenance.

• Clear Visual Indication: Often includes a mechanical flag indicator or LED to show the relay’s operational status (e.g., energized/tripped).

• Contact Multiplier: Provides a necessary number of isolated contacts from a single primary protection relay output.

4. Important Considerations (注意事项)

When installing and operating the Arteche BJ8BB, the following points are essential:

• Correct Voltage Selection: Ensure the coil’s rated voltage ($\mathbf{U_n}$) matches the control supply voltage in your panel. Incorrect voltage can damage the coil or prevent reliable operation.

• Contact Load: Do not exceed the specified maximum breaking and continuous carrying current ratings for the contacts to ensure their longevity.

• Wiring and Polarity: Follow the wiring diagrams precisely, especially when connecting DC coils. Observe proper polarity if a suppression diode is integrated.

• Environmental Protection: While robust, install the relay in a clean, protected enclosure, away from excessive vibration, moisture, and extreme temperatures.

• Surge Suppression: For DC coil circuits, it is highly recommended to use appropriate surge suppressors (like diodes or varistors) to protect the control circuit from inductive voltage spikes when the relay de-energizes.
