Allen-Bradley MPL-B4560F-MJ22AA 480V Low-Inertia Servo Motor

Description

Allen-Bradley MPL-B4560F-MJ22AA 480V Low-Inertia Servo Motor

Product Dimensions：

The Allen-Bradley MPL-B4560F-MJ22AA is a high-performance MP-Series™ Low-Inertia Brushless Servo Motor. These motors are designed to meet the demanding requirements of high-performance motion systems, providing high torque output in a compact, efficient package.

Product Detailed Description

The MPL-B4560F-MJ22AA is a rotary servo motor characterized by its low-inertia design, which allows for rapid acceleration and deceleration. This specific model belongs to the 400V class and features a 115mm frame size. The “MJ” in the model code indicates it is equipped with a multi-turn high-resolution encoder, providing absolute position feedback.

Technical Parameters

Product Advantages

• High Acceleration: The low rotor inertia is specifically engineered for applications requiring quick starts and stops, improving overall machine cycle times.
• High Torque Density: Utilizes high-energy rare-earth magnets to provide significant torque while maintaining a smaller physical footprint than standard motors.
• Precision Feedback: The multi-turn absolute encoder eliminates the need for a homing routine after power-up, saving time and improving system reliability.
• Smart Motor Technology: Includes an onboard memory chip that communicates motor identity and parameters to Allen-Bradley Kinetix drives, simplifying commissioning and reducing setup errors.
• Thermal Management: Designed with an innovative winding pattern that improves heat dissipation, extending the life of the motor.

Important Considerations & Precautions

• Environment (IP Rating): This standard model is IP50 rated. It is not protected against water or pressurized liquids. If your environment involves washdown or heavy oil spray, an optional shaft seal must be installed to reach IP66.
• Connector Handling: The circular bayonet connectors should be handled with care. Ensure they are fully seated and locked to prevent intermittent signal loss or arcing.
• Cable Length: High-resolution feedback signals are sensitive to electromagnetic interference (EMI). Use shielded Allen-Bradley 2090-series cables and keep them separated from high-voltage power lines.
• Mechanical Alignment: Precise alignment between the motor shaft and the load is critical. Misalignment can lead to premature bearing failure and vibration.

Product Applications

The MPL-B4560F-MJ22AA is typically used in precision-controlled machinery:

• Packaging Machinery: High-speed labeling, capping, and pick-and-place operations.
• Material Handling: Intelligent conveyor systems and automated storage/retrieval systems (AS/RS).
• Converting & Printing: Controlling tension and registration in paper or film processing.
• Automotive Assembly: Precise positioning for robotic cells and welding stations.
• Electronic Assembly: High-speed component placement on circuit boards.
