Allen-Bradley 2094-BMP5-S Axis Module

Description

Allen-Bradley 2094-BMP5-S Axis Module

Product Dimensions：

The Allen-Bradley 2094-BMP5-S is a high-performance Kinetix 6000 Axis Module featuring integrated Safe Torque Off (STO) functionality. It is a core component of Rockwell Automation’s multi-axis servo drive system, designed for precise motion control in high-speed, high-demand industrial applications.

Product Detailed Description

The 2094-BMP5-S is an IAM (Integrated Axis Module) or AM (Axis Module) power section that mounts onto a Kinetix 6000 power rail. The “-S” suffix denotes that it includes built-in safety features, allowing it to safely remove motor torque without disconnecting power from the entire drive system. It operates seamlessly via the SERCOS interface network, providing synchronized motion control for brush/brushless servo motors.

Technical Parameters

Product Advantages

• Space-Saving Module Design: Shares a common power rail and DC bus with other Kinetix 6000 modules, drastically reducing cabinet footprint, wiring complexity, and installation time.
• Integrated Safety (Safe Torque Off): Minimizes downtime by allowing safe entry into active machine zones. It prevents the drive from restarting unexpectedly without needing to cycle the main 3-phase power.
• Fiber-Optic Control (SERCOS): Utilizes a noise-immune fiber-optic ring network for motion commands, ensuring precise, real-time synchronization between multiple axes.
• Exceptional Dynamic Response: High peak current capabilities enable aggressive acceleration and deceleration profiles required for modern high-speed machines.

Important Considerations & Precautions

• Power Rail Compatibility: This module can only be installed on a compatible 2094 Power Rail. Ensure the rail alignment pins are properly seated before tightening the mounting screws.
• Fiber-Optic Cable Radius: When routing the SERCOS fiber-optic cables, maintain the minimum specified bend radius to prevent signal attenuation or permanent cable damage.
• Safety Circuit Validation: The Safe Torque Off (STO) function must be commissioned and validated according to local safety regulations before the machine is put into operation.
• Thermal Management: Multi-axis configurations generate considerable heat. Ensure the control cabinet has adequate ventilation or air conditioning to maintain the temperature below 50°C.

Product Applications

The 2094-BMP5-S is designed for high-performance, multi-axis industrial machinery:

• Packaging Machinery: Form-fill-seal machines, cartoning, and high-speed labeling systems.
• Material Handling: Multi-axis pick-and-place robots, sorting systems, and automated storage/retrieval systems (ASRS).
• Converting Equipment: Precision web handling, printing, and slitting applications requiring coordinated tension control.
• Assembly Automation: High-tolerance automotive sub-assembly cells and electronic component insertion machines.
