Allen‑Bradley 2094-PRS2 2-Axis Servo Drive Mounting Base

Description

Allen‑Bradley 2094-PRS2 2-Axis Servo Drive Mounting Base

Product Dimensions：

The Allen‑Bradley 2094-PRS2 is a high-performance Kinetix 6000 Slim Integrated Rail designed by Rockwell Automation. It serves as the physical and electrical backbone for mounting and interconnecting Kinetix 6000 multi-axis servo drives.

1. Product Description

The 2094-PRS2 is a 2-slot Integrated Rail. It provides a streamlined platform that eliminates the need for complex power wiring between drive modules. The rail includes the power bus and communication links necessary to connect an Integrated Axis Module (IAM) and one additional Axis Module (AM).

2. Technical Parameters

3. Product Advantages

• Reduced Wiring: The integrated power bus replaces individual power wires, significantly reducing assembly time and potential wiring errors.

• Space Efficiency: The “Slim” design minimizes the footprint inside the control cabinet, allowing for more compact machine designs.

• Scalability: While this model has 2 slots, the Kinetix 6000 system allows for easy expansion by choosing rails with more slots (up to 8).

• Enhanced Reliability: Solid-state connections on the rail reduce the risk of loose terminals or vibrations affecting power delivery.

4. Key Considerations & Precautions

• Slot Alignment: Ensure that the pins on the back of the drive modules are perfectly aligned with the rail connectors before tightening screws to avoid pin damage.

• Slot Fillers: If a slot is left empty, use a 2094-PRF slot filler module to protect the connectors from dust and maintain proper airflow.

• Torque Specifications: Always use a torque wrench to tighten the mounting bolts to the manufacturer’s specified limits to ensure a secure ground connection.

• Current Limits: Ensure the total power consumption of the connected modules does not exceed the rail’s maximum current capacity.

5. Product Applications

The 2094-PRS2 is ideal for small to mid-sized motion control systems requiring high precision and rapid response. Common industries include:

• Packaging Machinery: Cartoning, labeling, and form-fill-seal machines.

• Material Handling: Small-scale pick-and-place robots and sorters.

• Converting: Precision tension control and slitting applications.

• Assembly: Automated electronic component assembly lines.
