ABB UMC22-FBP.0 1SAJ510000R0100 Motor Controller

Description

ABB UMC22-FBP.0 1SAJ510000R0100 Motor Controller

The ABB UMC22-FBP.0 (Order Code: 1SAJ510000R0100) is a highly versatile and intelligent Universal Motor Controller. It is a key component in ABB’s motor management system, designed to provide comprehensive protection, control, and monitoring for three-phase AC motors in a single compact device.

Product Detailed Description

The UMC22-FBP.0 is an integrated motor protection and control relay that bridges the gap between traditional motor starters and high-end automation. It is a “FieldBusPlug” (FBP) compatible device, meaning it can be easily integrated into various communication protocols (like PROFIBUS, DeviceNet, or Modbus) simply by swapping the external plug. It monitors motor currents and voltages to protect against faults while providing detailed diagnostic data to the PLC or DCS.

Technical Parameters

Product Advantages

• Integrated Functions: Combines motor protection (overload, phase failure, etc.), control logic (start/stop), and monitoring into one unit, reducing wiring and panel space.
• Flexibility through FieldBusPlug: The “Neutral” communication interface allows the user to choose their preferred network (PROFIBUS DP, CANopen, DeviceNet, Modbus, Ethernet) just by changing the plug.
• Comprehensive Protection: Provides advanced features like earth fault detection, stall protection, and thermistor motor protection.
• Operational Reliability: Even if the communication with the PLC is lost, the UMC22 can be configured to continue running or shut down safely based on local parameters.
• Detailed Diagnostics: Provides data on motor operating hours, number of starts, and the cause of the last trip, facilitating rapid troubleshooting.

Important Considerations (Precautions)

• Power Supply: Ensure a stable 24 V DC supply. Significant voltage drops can cause the internal relays to chatter or the unit to reset.
• Current Selection: When using the internal current transformers, ensure the motor’s full-load current (FLC) falls within the 0.24–63 A range. For motors exceeding 63 A, appropriate external current transformers must be used and the transformation ratio must be programmed.
• Address Configuration: For fieldbus operation, the device address must be correctly set via the operator panel or software before it can communicate with the master controller.
• Safety Limits: While the UMC22 provides comprehensive protection, it is often used in conjunction with a separate circuit breaker for short-circuit protection.

Product Applications

The ABB UMC22-FBP.0 is widely used in Motor Control Centers (MCC) across various industries:

• Oil & Gas: Control of pumps and fans in hazardous and remote locations where high-reliability monitoring is required.
• Water & Wastewater: Managing multi-pump stations with complex start/stop sequences and dry-run protection.
• Chemical Industry: Protecting critical processing motors that require high trip class accuracy (e.g., Trip Class 30).
• Mining & Cement: Handling heavy-duty starting conditions for conveyors and crushers.
• Food & Beverage: Used in automated production lines where quick diagnostics are essential to minimize downtime.
