ABB TU515 C0 1SAP212200R000 I/O Module Terminal Base

Description

ABB TU515 C0 1SAP212200R000 I/O Module Terminal Base

Here is the detailed technical profile for the ABB TU515 (1SAP212200R000), which is a key component within the AC500 PLC ecosystem.

## Product Overview: ABB TU515 (1SAP212200R000)

The TU515 is an I/O Terminal Unit from the AC500 product line. It serves as the physical and electrical interface between the I/O modules and the field sensors/actuators. Specifically, it is designed for S500 I/O modules, providing a screw-type terminal connection system.

### Technical Specifications

## Key Advantages

• Modular Flexibility: The TU515 allows for “Permanent Wiring.” You can wire the terminal unit before the electronic I/O module is plugged in, which simplifies installation and maintenance.

• Ease of Replacement: If an I/O module fails, it can be swapped out without disconnecting any field wires, significantly reducing downtime.

• Reliable Connection: High-quality screw terminals ensure vibration-resistant connections, making it suitable for harsh industrial environments.

• Space Efficient: The compact design allows for high-density I/O configurations on a standard DIN rail.

## Important Precautions (Usage Notes)

1. Correct Seating: Ensure the I/O module is fully clicked into place to prevent communication errors or intermittent power supply to the module.

2. Voltage Limits: Do not exceed the rated 24 VDC supply. Using higher voltages can lead to permanent damage to the terminal unit and the attached I/O module.

3. Wiring Integrity: Ensure that the wire cross-sections are within the specified limits for the screw terminals to prevent overheating or loose connections.

4. Electrostatic Discharge (ESD): When handling the unit and plugging in modules, follow standard ESD protection protocols to avoid damaging sensitive electronic components.

## Product Applications

The TU515 is utilized wherever the ABB AC500 PLC system is deployed, including:

• Factory Automation: Connecting sensors, valves, and motors in assembly lines.

• Process Control: Integration with flow meters, pressure transmitters, and temperature sensors.

• Marine & Offshore: Used in control systems for ships and rigs (due to its robust design).

• Infrastructure: Building management systems, water treatment plants, and energy distribution monitoring.
