Description
ABB PDA11-FBP.050 1SAJ924009R0005 bus adapter
The ABB PDA11-FBP.050 (Order Code: 1SAJ924009R0005) is an adapter cable and connection accessory designed for the ABB FieldBusPlug (FBP) product line. It serves as an essential interface component to connect intelligent field devices—such as motor controllers (e.g., UMC100.3) or soft starters—to standard fieldbus networks (such as PROFIBUS DP, DeviceNet, or CANopen) via standard panel-mount connections.
Product Detailed Description
The PDA11-FBP.050 is a pre-assembled, shielded adapter cable featuring an M12 connector on one end and terminal/plug connections on the other. It acts as an extension or panel feed-through cable, allowing smooth signal and power transmission between ABB FieldBusPlug devices mounted inside an enclosure and the external fieldbus network backbone.
Technical Parameters
| Parameter | Specification |
| Model / Type | PDA11-FBP.050 |
| Order Code | 1SAJ924009R0005 |
| Manufacturer | ABB |
| Product Family | FieldBusPlug Accessories |
| Cable Length | 0.50 meters (50 cm / ~1.64 ft) |
| Connector Type | M12 round connector (Fieldbus standard) |
| Shielding | Shielded cable (EMI/RFI protection) |
| Degree of Protection | IP65 / IP67 (when properly mated and sealed) |
| Ambient Temperature | -25°C to +70°C (Operation) |
Product Advantages
- Plug-and-Play Installation: Pre-formed connector design minimizes wiring errors and significantly speeds up cabinet assembly and field commissioning.
- High Reliability & Noise Immunity: Integrated full shielding protects sensitive digital communications from electromagnetic interference (EMI) typical in industrial motor control environments.
- Rugged Industrial Design: IP65/IP67 rated connections ensure resistance against dust, moisture, and chemical exposure in harsh industrial plants.
- Standardized Compatibility: Designed specifically to integrate with ABB’s FieldBusPlug system, enabling universal protocol adaptation across different fieldbus standards.
Important Considerations & Precautions
- Tightening Torque: Ensure M12 connections are hand-tightened or torqued to specified manufacturer values (typically ~0.6 N·m) to maintain IP rating without stripping the threads.
- Bend Radius: Do not exceed the minimum allowable bend radius during cabinet routing to avoid damaging internal shielding and wire conductors.
- Protocol & Cable Distance: Verify overall fieldbus network segment lengths when adding drop cables/adapters to avoid signal degradation on high-baud-rate networks like PROFIBUS DP.
- Power De-energization: Always disconnect system power before connecting or disconnecting adapter cables to avoid potential bus errors or electrical arcing.
Product Applications
- Motor Control Centers (MCC): Connecting intelligent motor controllers (like ABB UMC series) inside draw-out units to the main cabinet fieldbus backbone.
- Soft Starter & VFD Monitoring: Interfacing soft starters and drives with central PLCs via fieldbus communication.
- Industrial Automation & Process Plants: Packaging, material handling, water treatment, and manufacturing assembly lines using ABB FieldBusPlug architecture.
Shipping Port: Xiamen, China
Payment: Bank of Chicago, Bank of Singapore
Express cooperation: fedex, DHL, UPS and your express account
Service: Professional Sales provides 24 hours /7 days online service
Please make an inquiry for more models：
