ABB NDIO-02-KIT Inverter I/O Expansion Module Kit

Description

ABB NDIO-02-KIT Inverter I/O Expansion Module Kit

The ABB NDIO-02-KIT is a specialized Digital I/O Expansion kit designed for use with ABB’s industrial drives, most notably the ACS800 and ACS880 series. It allows for the expansion of the drive’s control capabilities by adding digital input and output channels.

Product Detailed Description

The NDIO-02-KIT is an interface module that provides an additional set of digital inputs and outputs to the drive’s control unit. The kit typically includes the NDIO-02 module, mounting hardware, and the necessary fiber optic or ribbon cables to interface with the drive’s main control board (such as the RMIO or BCU).

Technical Parameters

Product Advantages

• Extended Control: Provides additional I/O points without needing a separate PLC for simple logic, reducing overall system complexity.
• Galvanic Isolation: High-quality isolation protects the drive’s sensitive control electronics from external electrical noise and ground loops.
• Seamless Integration: Because it communicates via the native DDCS protocol, the drive recognizes the I/O expansion immediately within the standard parameter settings.
• Flexible Logic: The added inputs and outputs can be mapped to various drive functions, such as “Ready,” “Fault,” “Remote Start,” or “Interlock.”

Important Considerations (Precautions)

• Fiber Optic Handling: The kit uses plastic fiber optic (POF) cables. Do not bend these cables sharply (minimum bend radius is usually 25mm), as this will cause signal loss and communication errors.
• Node Addressing: Ensure the station address switches (if applicable) on the module are set correctly so the drive can identify the module on the DDCS link.
• Power Supply: If using an external 24V DC supply for the digital inputs, ensure it shares a common ground with the drive’s control logic as specified in the manual.
• Firmware Version: Verify that the drive’s firmware supports the NDIO-02 module. Older ACS800 firmware may require an update to utilize all expansion features.

Product Applications

• Pumping Stations: Using additional inputs for “Low Level” or “High Pressure” switches that act as safety interlocks.
• Complex Conveyors: Providing feedback to a master controller or driving local signaling lamps (Run/Fault lights).
• Multi-Drive Systems: Coordinating “Run” signals between several drives in a master-follower configuration.
• Custom OEM Machinery: Interfacing the drive directly with auxiliary equipment like cooling fans, brake resistors, or external safety relays.
