ABB DC532 1SAP240100R0001 AC500 Mixed Digital Input/Output Module

Description

ABB DC532 1SAP240100R0001 AC500 Mixed Digital Input/Output Module

The ABB DC532 (1SAP240100R0001) is a high-density digital input/output module from the AC500 PLC (Programmable Logic Controller) family. It is specifically designed for the S500 I/O bus system to provide flexible and compact expansion for industrial automation tasks.

Product Detailed Description

The DC532 is a “configurable” I/O module. This means its channels can be defined by the user to act as either inputs or outputs, offering extreme flexibility in panel design. It communicates with the AC500 CPU via the I/O bus and is typically mounted on a TU511 or TU512 terminal unit (sold separately).

Technical Parameters

Product Advantages

• High Density: With 32 channels in a single compact module, it significantly reduces the footprint required in the control cabinet.

• Configurable Flexibility: The 16 “transistor-configurable” channels allow the same module to be adapted to different machine configurations without changing hardware.

• Advanced Diagnostics: Includes comprehensive LED status indicators for each channel and internal diagnostics that report errors (like short circuits or overloads) back to the CPU.

• Hot-Swap Capability: When used with the appropriate terminal units, modules can be replaced without disturbing the permanent wiring.

Important Considerations (Precautions)

• Terminal Unit Required: This module is an electronic unit only. It must be plugged into a compatible Terminal Unit (e.g., TU511 for screw terminals or TU512 for spring terminals) to function.

• Power Supply: Ensure a stable 24 V DC supply. High-voltage transients or unstable DC power can damage the transistor outputs.

• Current Limits: Do not exceed the 8 A total module current. If you are driving 16 outputs at 0.5 A simultaneously, you are at the limit; ensure proper thermal management/ventilation.

• Wiring: Use shielded cables for I/O lines if the environment is subject to high electromagnetic interference (EMI).

Product Applications

The DC532 is widely used in complex automation environments where space is a premium:

• Factory Automation: Controlling sensors, solenoids, and small actuators on assembly lines.

• Machine Building: Ideal for OEMs building standardized machines that may require slight variations in I/O counts.

• Process Control: Interfacing with push-buttons, limit switches, and signaling lamps in water treatment or food & beverage plants.

• Infrastructure: Managing lighting, ventilation, and power monitoring in large-scale building automation.
