ABB 64378660G Inverter Control Panel
The ABB 64378660G (also identified by the type code CDP312R) is a specialized control panel and keypad interface. It is a legacy but critical component used primarily for the local operation, configuration, and monitoring of ABB’s industrial variable frequency drives (VFDs).
Product Detailed Description
The 64378660G is the detachable control panel for the ACS600 and ACS800 series of high-power industrial drives. It features a multi-line alphanumeric LCD and a tactile keypad that allows operators to access drive parameters, view real-time signals (like motor speed, current, and torque), and perform local start/stop commands.
Technical Parameters
| Feature | Specification |
| Model / Type | CDP312R |
| Part Number | 64378660G (Alternate: 68281059 / 3ABD64378660) |
| Display Type | Alphanumeric LCD (typically 4 lines x 20 characters) |
| Interface Port | RS-485 (via 6-pin telephone-style or D-sub connector) |
| Input Voltage | 24 V DC (supplied by the drive control unit) |
| Operating Temp | 0°C to +50°C |
| Protection Class | IP54 (when panel-mounted with a gasket) |
| Weight | Approx. 140g |
| Housing Material | Industrial-grade plastic (Flammability rating 94V-0) |
Product Advantages
- Multi-Drive Control: A single CDP312R panel can be used to control a network of up to 31 drives if they are linked via the drive’s communication bus.
- Parameter Backup: The module can upload and store a complete set of drive parameters. This is highly useful for “cloning” settings to a replacement drive or restoring settings after a factory reset.
- Diagnostic Visualization: It provides clear text descriptions of faults and warnings, significantly speeding up the troubleshooting process compared to simple LED-based indicators.
- Hot-Pluggable: The panel can typically be connected or disconnected while the drive is powered (though local control should be switched to “Remote” first to avoid accidental stops).
Important Considerations & Precautions
- Mounting Requirement: If mounting the panel on a cabinet door rather than directly on the drive, a specific mounting platform kit (such as the RPMP-11 or RPMP-13) and a high-quality shielded cable are required.
- Firmware Matching: While generally backward compatible, ensure the CDP312R version aligns with the drive’s firmware for full access to all advanced parameter groups.
- Environmental Sealing: If used in wash-down or high-dust environments, ensure the mounting gasket is intact to maintain the IP54 rating.
- Cleaning: Use only a soft, damp cloth. Avoid harsh chemical solvents that could cloud the LCD screen or degrade the membrane keypad.
Product Applications
The 64378660G is used wherever ABB ACS600 or ACS800 drives are installed:
- Heavy Industry: Managing large motors in steel mills, paper plants, and mining conveyors.
- Marine & Offshore: Control panels for thrusters, winches, and propulsion systems on vessels.
- Water Management: Local interface for high-capacity pumps and aeration blowers.
- HVAC: Large-scale fan and cooling tower control in commercial infrastructure.
