ABB 2TLA020070R6900 Pluto Communication Cable

Description

ABB 2TLA020070R6900 Pluto Communication Cable

The ABB 2TLA020070R6900 (also known as the Pluto B42 AS-i) is a safety PLC from the ABB Jokab Safety Pluto product family. It is an intelligent, compact safety controller featuring an integrated AS-Interface (AS-i) bus interface, designed to handle medium-to-large machine safety applications with distributed safety sensors.

Product Detailed Description

The Pluto B42 AS-i functions as a standalone or networked safety controller. It processes safety inputs from device networks and physical wiring to execute safety logic programmed in the Pluto Manager software.

The B42 AS-i variant is equipped with 42 total I/O terminals and includes a built-in AS-i bus module. This allows it to act as an AS-i safety monitor or node, seamlessly reading safety signals over an AS-i cable (e.g., light curtains, emergency stops, safety switches) while simultaneously controlling local safety outputs.

Product Specifications

Product Advantages

• Reduced Cabling via AS-i: The integrated AS-Interface allows long runs of safe field devices to be connected over a single 2-wire ribbon cable, drastically reducing cabinet wiring time and terminal footprints.
• Pluto Bus Networking: Supports peer-to-peer safety communication across up to 32 Pluto units on a dedicated CAN-based Pluto safety bus without requiring an expensive central safety master.
• Flexible Dual-Function I/O: Many I/O terminals can be dynamically configured in software as either safety inputs, non-safety outputs, or pulse outputs for cross-fault monitoring.
• Free, Easy Programming: Configured using Pluto Manager, which features certified function blocks for all standard safety equipment (light curtains, E-stops, two-hand controls, muting).

Important Considerations & Precautions

• AS-i Master Requirement: Ensure the AS-i bus architecture is properly configured with an appropriate AS-i power supply (typically 30 V DC) and designated bus master/monitor settings.
• Relay Output Ratings: Observe maximum current and voltage limits on the 4 relay output channels to avoid contact welding; use external surge suppressors across inductive loads.
• ID / Address Configuration: Every Pluto unit on a Pluto bus and every device on the AS-i network must have a unique node address configured prior to system commissioning.
• Enclosure Protection: The module carries an IP20 rating and must be installed inside an IP54-rated (or better) control cabinet protected from dust and moisture.

Product Applications

• Distributed Safety Networks: Large automated manufacturing lines requiring safety communication across extended distances using AS-i cables.
• Packaging Machines: Managing interlocking guards, safety light grids, and emergency stop circuits across multi-zone packaging systems.
• Robotic Work Cells: Coordinating peripheral door switches, safety mats, and light curtains back to a central cell safety controller.
• Material Handling & Conveyors: Monitoring distributed E-stop pull-wire switches along extensive conveyor belts.
