AB 2093-AC05-MP1 Integrated Axis Module

Description

AB 2093-AC05-MP1 Integrated Axis Module

Product Dimensions：

AB 2093-AC05-MP1 Product Overview

The 2093-AC05-MP1 is a high-performance, compact servo drive belonging to the Kinetix 350 series. Designed for integrated motion on EtherNet/IP, it provides a cost-effective solution for machines that require fewer axes but demand high precision and seamless integration with Logix controllers.

Technical Specifications (Product Parameters)

Key Product Advantages

• Integrated Motion on EtherNet/IP: Simplifies the network architecture by eliminating the need for a dedicated motion network.

• Space-Saving Design: Its compact footprint allows for smaller control cabinets, which is ideal for modular machine designs.

• Enhanced Safety: The built-in Safe Torque Off (STO) function allows for increased productivity by keeping the drive powered while ensuring the motor cannot restart during maintenance or stops.

• Seamless Integration: Fully compatible with Studio 5000 Logix Designer, allowing for easy configuration, programming, and commissioning.

• Flexible Feedback: Supports various encoder types, providing flexibility in motor selection (e.g., MP-Series or TL-Series).

Important Considerations & Precautions

• Heat Dissipation: Ensure adequate clearance around the drive as specified in the manual to prevent overheating. Use an external cooling fan if operating in high-ambient temperatures.

• Proper Grounding: To minimize EMI (Electromagnetic Interference), the drive must be properly grounded to a subpanel using shielded cables for motor connections.

• Voltage Matching: Verify that the AC input voltage matches the drive’s rating before power-up; applying 480V to this model will cause permanent damage.

• Firmware Compatibility: Ensure the drive firmware is compatible with the version of Studio 5000 and the controller firmware being used.

Product Applications

The 2093-AC05-MP1 is widely used in industries requiring precise speed and position control, including:

1. Packaging Machinery: Vertical and horizontal form-fill-seal (VFFS/HFFS) machines.

2. Material Handling: Small conveyors, smart sorters, and pick-and-place robots.

3. Assembly Systems: Indexing tables, screw driving, and light-duty pressing.

4. Food & Beverage: Filling, capping, and labeling applications where washdown-rated motors are paired with the drive.

5. Printing & Labeling: High-speed labeling and registration control.
