A-B 1764-24BWA Controller

Description

A-B 1764-24BWA Controller

Product Dimensions：

The Allen-Bradley 1764-24BWA is the base unit (controller) for the MicroLogix 1500 programmable logic controller system. It is a highly versatile and expandable controller designed to bridge the gap between micro-PLCs and larger chassis-based systems.

Product Detailed Description

The 1764-24BWA consists of the Base Unit, which contains the power supply, embedded I/O, and the housing for the 1764-LRP or 1764-LSP Processor Unit. This modular design allows users to replace the processor without disturbing the field wiring, making maintenance significantly easier.

Technical Parameters

Product Advantages

• Modular Architecture: By separating the processor from the base, Allen-Bradley allows for easier hardware upgrades and lower spare-parts inventory costs.
• High Expandability: It uses the same 1769 Compact I/O modules as the CompactLogix series, allowing for a massive range of digital, analog, and specialty modules.
• High-Speed Features: The embedded inputs support high-speed latching and pulse-catching functions, which are essential for fast-moving production lines.
• Robust Relay Outputs: The 12 relay outputs are isolated, allowing the control of different voltage levels (e.g., 24V DC and 120V AC) within the same unit.
• Reliability: The MicroLogix 1500 series is famous for its “tank-like” durability in harsh industrial environments.

Important Considerations (Precautions)

• Processor Requirement: Note that the 1764-24BWA is just the Base. It cannot function without a processor unit (1764-LSP or 1764-LRP) plugged into the front slot.
• Expansion Power: When adding 1769 I/O modules, you must calculate the Power Supply Distance Rating. If you add too many modules, the voltage may drop, requiring an additional expansion power supply.
• DC Input Power: While the Base is powered by AC, the inputs require an external 24V DC power source to trigger.
• Heat Dissipation: Ensure the controller is mounted horizontally. Vertical mounting can lead to overheating and premature failure of the internal power supply.

Product Applications

The 1764-24BWA is a “workhorse” found in various mid-sized automation tasks:

• Conveyor Control: Managing sorting, counting, and motor control in distribution centers.
• Packaging Machinery: Coordinating baggers, sealers, and labeling machines.
• Pump Control: Managing water pressure and flow in municipal pump stations.
• Material Handling: Controlling small lifts, palletizers, and robotic pick-and-place stations.
• Legacy Integration: Often used to replace older MicroLogix 1000 systems when more I/O or memory is required.
