8000-KAAT Allen‑Bradley Central control module

Description

8000-KAAT Allen‑Bradley Central control module

Product Dimensions：

Product Description

The Allen-Bradley Central Control Module, a key component in Rockwell Automation’s industrial control systems, serves as the primary processing unit within Programmable Logic Controller (PLC) or Programmable Automation Controller (PAC) architectures. It manages critical tasks such as logic execution, data processing, communication, and system coordination, acting as the central hub in complex automation setups. Commonly integrated into platforms like ControlLogix, CompactLogix, and SLC 500 series, it ensures seamless interaction with I/O modules, HMIs, SCADA systems, and other networked devices.

Product Specifications

The specifications vary depending on the specific module (e.g., ControlLogix 1756 series, CompactLogix 1769 series, or SLC 500 1747 series). Below are general specifications for a typical Allen-Bradley Central Control Module (e.g., 1756-L8x ControlLogix series):

• Processor: High-performance 32-bit or 64-bit processor for fast logic execution.

• Memory:

  • User Memory: Up to 32 MB (non-volatile).

  • I/O Memory: Configurable, typically 1 MB or more.

• Communication Ports:

  • Ethernet/IP, ControlNet, DeviceNet, or serial communication options.

  • Supports multiple protocols (e.g., Modbus, OPC UA).

• Power Supply: 5V DC or 24V DC, depending on the module.

• Operating Temperature: 0°C to 60°C (32°F to 140°F).

• Environmental Rating: IP20, suitable for industrial environments.

• Control Modes: Supports V/f control, sensorless vector control, and closed-loop vector control for motor applications.

• Certifications: UL, CE, and NEMA standards compliance.

For precise specifications, refer to the specific model’s technical documentation (e.g., CENTERLINE 2100 or 2500 MCC documentation).

Product Advantages

• Reliability: Built for rugged industrial environments, ensuring consistent performance under harsh conditions.

• Flexibility: Configurable for diverse application needs, from simple to complex automation tasks.

• Scalability: Supports systems ranging from small-scale setups to large, distributed control architectures.

• Seamless Integration: Compatible with Rockwell Automation’s ecosystem, including I/O modules, HMIs, and software like Studio 5000.

• Advanced Diagnostics: Provides real-time diagnostic data and predictive analytics to minimize downtime.

• Safety Features: Incorporates ArcShield™ technology for arc flash protection in high-current applications, enhancing workplace safety.

• Fast Delivery Options: Standard configurations (e.g., 380V/400V, 50 Hz) are available with reduced lead times.

Precautions

• Installation: Ensure proper grounding and adherence to voltage ratings to prevent electrical faults. Use qualified personnel for installation.

• Environmental Conditions: Operate within specified temperature and humidity ranges to avoid damage. Avoid exposure to excessive dust or corrosive substances.

• Configuration: Verify compatibility with connected devices and update firmware regularly to maintain system integrity.

• Maintenance: Regularly check for loose connections, overheating, or wear in high-vibration environments. Use Rockwell Automation’s recommended maintenance schedules.

• Safety: Implement lockout-tagout procedures during maintenance to prevent arc flash incidents, especially in high-amp applications.

• Software Updates: Use only authorized Rockwell Automation software for programming to avoid compatibility issues.

Product Applications

The Allen-Bradley Central Control Module is widely used across industries for automation and control tasks, including:

• Manufacturing: Coordinates assembly lines, robotic systems, and material handling in automotive and consumer goods production.

• Oil and Gas: Manages motor control centers for pumps, compressors, and drilling equipment, with enhanced safety features like ArcShield™ for high-current applications.

• Food and Beverage: Controls processing, packaging, and conveyor systems with precise motor control and integration with SCADA systems.

• Water Treatment: Oversees pumps and filtration systems, ensuring reliable operation in harsh environments.

• Mining: Supports heavy machinery control with scalable and rugged solutions for demanding conditions.

• Power Generation: Manages motor control for turbines and generators, with options for high-amp applications and arc flash protection.

For detailed configuration guidelines, refer to the CENTERLINE 2100 Motor Control Centers Program Guide (publication 2100-CA004).
