Description
1769-OW8I A-B Central control module
Product Dimensions：
Product Description
The Allen-Bradley 8-Channel Analog Output Module is a high-performance I/O module designed for use in CompactLogix and ControlLogix systems. It provides eight analog output channels capable of converting digital signals from the PLC into precise analog voltage or current signals. This module is ideal for controlling devices such as actuators, drives, valves, and other field instruments that require smooth and accurate analog control.
Product Specifications
| Parameter | Value/Details |
|---|---|
| Part Number | e.g., 1769-OF8C (current output), 1769-OF8V (voltage output) |
| Number of Channels | 8 |
| Output Type | Current (4–20 mA) or Voltage (0–10 V DC) |
| Resolution | 14–16 bits (depending on model) |
| Update Rate | Typically 1–5 ms per channel |
| Isolation | Channel-to-channel and channel-to-bus isolation |
| Communication | Backplane communication with CompactLogix/ControlLogix |
| Operating Temperature | 0–60 °C (32–140 °F) |
| Power Dissipation | ~3.5 W at full load |
| Terminal Block | Removable, spring-clamp or screw terminals |
| Compatibility | RSLogix/Studio 5000 programming environment |
| Certifications | UL, CE, C-Tick, KC, RoHS |
Product Advantages
- High Accuracy & Resolution: Provides precise analog output signals essential for fine-tuned process control.
- Flexible Output Types: Available in both current and voltage output versions to suit a wide range of industrial devices.
- Fast Response Time: Rapid update rates ensure real-time control in dynamic systems.
- Robust Isolation: Prevents noise interference and protects the PLC and connected equipment.
- Compact Design: Saves space in control cabinets while offering high channel density.
- Easy Integration: Fully compatible with Allen-Bradley PLC systems and Studio 5000 software.
- Diagnostics Support: Built-in diagnostics help detect open-circuit, over-range, and under-range conditions.
- Removable Terminal Blocks: Simplify installation, maintenance, and replacement.
Precautions
- Proper Grounding: Ensure correct grounding to avoid signal noise and ensure accurate output.
- Wiring Verification: Double-check wiring polarity and connections to prevent damage to the module or field devices.
- Load Compatibility: Ensure connected devices are compatible with the output type (current or voltage) and range.
- Environmental Conditions: Avoid exposure to moisture, extreme temperatures, or corrosive environments unless properly protected.
- Overcurrent Protection: Avoid short circuits or overcurrent conditions that may damage the module.
- Firmware Compatibility: Ensure the PLC firmware and RSLogix/Studio 5000 version are compatible with the module.
- Heat Dissipation: Provide adequate ventilation in the control cabinet to prevent overheating.
Product Applications
- Process Control: Control valves, variable speed drives, and flow regulators in chemical, petrochemical, and pharmaceutical industries.
- Motion Control: Interface with servo and stepper drives for position, velocity, and torque control.
- Building Automation: Modulate HVAC systems, lighting controls, and environmental monitoring.
- Test and Measurement: Provide analog signals for calibration, simulation, and automated test equipment.
- Water and Wastewater Management: Regulate pump speeds, chemical dosing, and valve positioning.
- Power Generation: Control generator excitation, fuel flow, and steam valve positioning.
- Food and Beverage: Precise control of mixers, cookers, and packaging machinery.
- Material Handling: Adjust conveyor speeds, robotic arms, and automated guided vehicles (AGVs).
