1769-L35E1336-GM1 A-B Programmable controller

Description

1769-L35E1336-GM1 A-B Programmable controller

Product Dimensions：

The Central Processing Units from Allen-Bradley are the core of Rockwell Automation’s Programmable Logic Controller (PLC) systems. They are responsible for executing user programs, managing Input/Output (I/O) devices, processing data, and communicating with other automation components. A-B’s CPU series are known for their powerful performance, reliability, and scalability, making them suitable for applications ranging from simple machine control to complex process automation.

Product Detailed Description (Using ControlLogix Series as an Example)

• Function:
  • Program Execution: Runs user-written control programs to provide automated control of machines and processes.
  • I/O Management: Scans and manages local, remote, and distributed I/O modules to collect field data and control equipment.
  • Data Processing: Handles arithmetic, logical, and data manipulation operations to support complex control algorithms.
  • Communication: Provides built-in and expansion communication interfaces to communicate with other PLCs, HMIs, SCADA systems, and enterprise-level networks.
  • Diagnostics: Offers built-in diagnostic capabilities to monitor system status, faults, and performance.
• Features:
  • High Performance: Utilizes powerful processors to support high-speed program execution and I/O scanning, suitable for high-speed and time-critical applications.
  • Modular and Scalable: Based on a chassis-based design, it supports the insertion of various I/O and communication modules, making it easy to expand to meet growing system requirements.
  • Redundancy Support: Certain high-end models support processor and power supply redundancy for High-Availability applications to minimize downtime.
  • Integrated Safety Functions: Some models (e.g., GuardLogix) integrate TÜV-certified safety functions, making them suitable for safety-critical applications.
  • Open Architecture: Supports a variety of industrial communication protocols, making it easy to integrate with equipment from other vendors.
  • Studio 5000 Programming Environment: Programmed using Rockwell Automation’s Studio 5000 Logix Designer software, which provides powerful tools for development, debugging, and maintenance.

Product Parameters (Using ControlLogix 5580 Series as an Example)

• Processor Type: Modern multi-core processors.
• Memory Capacity: Various options available, from a few MB to tens of MB.
• Communication Interfaces:
  • Built-in EtherNet/IP ports with CIP Security support.
  • USB port for local connection.
  • Optional modules supporting ControlNet, DeviceNet, PROFIBUS, etc.
• I/O Capacity:
  • Supports hundreds to thousands of digital and analog I/O points.
  • Can be expanded across multiple chassis and networks.
• Programming Languages:
  • Ladder Logic.
  • Function Block Diagram.
  • Structured Text.
  • Sequential Function Chart.
• Power Requirements:
  • Powered by the chassis power supply.
• Environment:
  • Operating Temperature: 0°C to 60°C.
  • Vibration and Shock: Compliant with industrial standards.
• Certifications:
  • UL, cUL, CE, TÜV (for safety models), etc.

Product Advantages

• Industry-Leading Performance: Capable of handling the most complex control tasks and supporting fast response times.
• High Reliability and Availability: Robust design and redundancy options ensure operation in critical applications.
• Powerful Scalability: The modular platform allows for easy addition of I/O and functionality as needs change.
• Integrated Safety Functions: Unifies standard and safety control on a single platform, simplifying system design and maintenance.
• Easy to Program and Maintain: A single programming software and powerful diagnostic tools simplify development and troubleshooting.
• Global Brand and Support: Rockwell Automation provides extensive global technical support, training, and product services.

Precautions

• Correct Selection: Choose the appropriate CPU model based on application needs (number of I/O points, program complexity, communication requirements, redundancy needs, etc.).
• Programming Software: Requires licensed Studio 5000 Logix Designer software from Rockwell Automation.
• Power and Grounding: Ensure a compatible power supply module is used and proper grounding is performed to prevent electrical interference.
• Firmware Management: Regularly check for and update firmware to get the latest features and security patches.
• Safety Procedures: Always follow relevant safety procedures during installation, maintenance, and programming, especially when dealing with safety models.

Product Applications

A-B’s CPUs are widely used across various industries, including:

• Automotive Manufacturing: Robot control, assembly line automation.
• Food and Beverage: Filling, packaging, and pasteurization process control.
• Pharmaceutical: Batch processing, validation, and compliance requirements.
• Oil & Gas: Monitoring and control of pipelines, drilling rigs, and refineries.
• Water Treatment: Control of pump stations, valves, and flow rates.
• General Automation: Machine control, conveyor systems, material handling, and robotic integration.
