1763-L16BBB Central control module
Product Dimensions：
Product Description
The Allen-Bradley DC Output Module is a family of solid-state output modules designed for use in Allen-Bradley PLC systems such as ControlLogix, CompactLogix, and MicroLogix. These modules provide transistor-based outputs to control DC loads like solenoids, relays, indicator lamps, motor starters, and other industrial devices. They are essential components in digital output systems, offering reliable and fast switching for automation applications.
Product Specifications
| Specification | Details |
|---|---|
| Module Types | 8-point, 16-point, 32-point variants |
| Output Type | Sinking or Sourcing (depending on model) |
| Voltage Range | Typically 12–24V DC |
| Current per Point | Up to 0.5A or 2A (varies by model) |
| Isolation | Optical isolation between channels and backplane |
| Backplane Current | Typically 80–200 mA |
| Indicator LEDs | Per-point status indication |
| Removable Terminal Block | Yes (on most models) |
| Operating Temperature | 0–60°C (32–140°F) |
| Compatibility | Compatible with Allen-Bradley PLCs and I/O chassis |
Product Advantages
- High-Speed Switching: Transistor-based outputs provide fast response times suitable for high-speed automation.
- Energy Efficient: Low power consumption compared to mechanical relays.
- Long Service Life: Solid-state design ensures longer operational life with no moving parts.
- Per-Point Status Indication: Integrated LEDs allow for quick diagnostics and troubleshooting.
- Modular Design: Easy installation and replacement with hot-swappable support on certain platforms.
- Flexible Configurations: Available in sinking or sourcing types to match field device requirements.
- Robust Isolation: Optical isolation protects the PLC backplane from field voltage spikes and noise.
Precautions
- Polarity Matching: Ensure proper polarity (sinking vs. sourcing) when connecting to field devices.
- Overcurrent Protection: Avoid exceeding the maximum current rating per point or per module to prevent damage.
- Heat Dissipation: Install modules in adequately ventilated enclosures, especially when operating near maximum load.
- Surge Protection: Use external suppression devices (e.g., diodes for inductive loads) to protect against voltage spikes.
- Wiring Verification: Double-check wiring before powering up the system to avoid short circuits or misconfigurations.
- Environmental Conditions: Ensure operating environment stays within specified temperature and humidity limits.
Product Applications
- Industrial Automation: Controlling solenoids, actuators, and relays in assembly lines.
- Material Handling: Managing conveyors, diverters, and sorters in logistics systems.
- Packaging Machinery: Activating feeders, sealers, and reject mechanisms.
- Process Control: Switching valves, pumps, and alarms in water treatment or chemical plants.
- HVAC Systems: Controlling dampers, fans, and indicators in building automation.
- Test and Measurement: Driving loads in automated test benches and diagnostic equipment.
- Safety Systems: Interfacing with light curtains, emergency stops, and safety relays.
