1746-OB32E A-B Central control module
1746-OB32E A-B Central control module - Image 2
1746-OB32E A-B Central control module - Image 3

1746-OB32E A-B Central control module

Brand： A-B

Model number：1746-OB32E

Colour：new                                    Warranty: 12 months

Lead Time：3-day working day   Country of origin: USA

Price: Please contact us         Product weight：0.25kg

Get a Quote
Category: SKU: 1746-OB32E Brand:

Description

1746-OB32E A-B Central control module

Product Dimensions：

Product Description

The Allen-Bradley 1746-OB32E is a 32-channel digital output module designed for use in the SLC 500 programmable logic controller (PLC) system. It provides isolated, high-density digital outputs to control a wide range of field devices such as relays, motor starters, indicator lamps, and solenoids. The module is engineered for robust performance in industrial environments, offering reliable signal control and seamless integration into automation systems.

Product Specifications

Parameter Description
Part Number 1746-OB32E
Type Digital Output Module
Number of Outputs 32 (grouped in four banks of 8)
Output Type Sourcing (PNP), Current Sinking
Voltage Range 10–30V DC
Output Current 0.5A per point, 2A per bank (max)
Isolation 1500V AC between field side and logic side
Backplane Current 360mA at 5V DC
Indicator LEDs One per output point
Operating Temperature 0–60°C (32–140°F)
Compatibility Allen-Bradley SLC 500 PLC systems
Certifications UL, CSA, CE, C-Tick

Product Advantages

  • High Channel Density: 32 outputs in a single module reduce panel space and simplify wiring.
  • Flexible Grouping: Outputs are grouped in four banks of 8, allowing different voltage levels or commons within the same module.
  • Robust Isolation: High isolation voltage protects the PLC backplane and logic from field disturbances.
  • Status Indication: Individual LEDs per point provide quick visual diagnostics.
  • Wide Voltage Range: Compatible with various industrial DC control voltages.
  • Reliability: Designed for continuous operation in harsh industrial environments.

Precautions

  • Heat Dissipation: Ensure adequate ventilation around the module, especially when operating near maximum current.
  • Power Supply Limits: Do not exceed the maximum current per point or per bank to avoid damage.
  • Wiring Practices: Use proper wire gauges and secure connections to prevent voltage drop or intermittent operation.
  • Grounding: Follow proper grounding practices to minimize electrical noise and ensure safety.
  • Environmental Compatibility: Avoid exposure to extreme temperatures, humidity, or corrosive atmospheres unless the enclosure is appropriately rated.

Product Applications

  • Manufacturing Automation: Controls actuators, relays, and pilot lights in assembly lines and robotic cells.
  • Process Control: Manages valves, pumps, and alarms in water treatment, chemical processing, and oil & gas industries.
  • Material Handling: Drives conveyor motors, diverters, and sorters in distribution centers.
  • Packaging Machinery: Activates solenoids and cylinders in filling, sealing, and labeling equipment.
  • Building Automation: Interfaces with lighting systems, HVAC controls, and security devices.
