100S-C12KD23C Allen‑Bradley Safety contactors

Description

100S-C12KD23C Allen‑Bradley Safety contactors

Product Dimensions：

Product Description

The Allen-Bradley 100S-C12KD23C is a safety contactor from the Bulletin 100S-C series, designed for industrial applications requiring reliable safety control. It features mechanically linked, positively guided contacts, ensuring compliance with modern safety standards. This contactor is ideal for environments where precise motor control and safety are critical.

Product Specifications

• Brand: Allen-Bradley

• Series: Bulletin 100S-C

• Part Number: 100S-C12KD23C

• Coil Voltage: 110 V AC (50/60 Hz)

• Contact Current Rating: 12 A

• Contact Voltage Rating: 525 V AC

• Number of Poles: 3 Normally Open (N.O.) power poles

• Auxiliary Contact Configuration: 2 Normally Open (N.O.) + 3 Normally Closed (N.C.)

• Terminal Type: Screw

• Dimensions:

  • Length: 81 mm

  • Width: 45 mm

  • Depth: 119.5 mm

• Operating Temperature Range: -25°C to +60°C

• Weight: Approximately 0.456 kg (1 lb)

• Certifications: SUVA LVD Type Approval, Korean KC, IECEE Scheme (as of July 19, 2025)

Product Advantages

• Enhanced Safety: Mechanically linked contacts ensure that auxiliary contacts do not change state if a power pole welds, critical for safety applications.

• Reliable Low-Energy Performance: Gold-plated bifurcated auxiliary contacts are optimized for low-energy feedback circuits, ensuring dependable operation in complex control systems.

• Durability: Built for high durability, suitable for harsh industrial environments.

• Visible Status Indication: A protective cover with a window allows easy monitoring of ON/OFF status while preventing manual operation.

• Compact Design: Space-efficient dimensions make it easy to integrate into control panels.

• Compliance: Meets international safety standards, ensuring reliability in safety-critical applications.

Precautions

• Discontinued Product: The 100S-C12KD23C was discontinued by the manufacturer on December 31, 2021. Availability may be limited to surplus or refurbished stock, and buyers should verify compatibility with current systems.

• Non-Authorized Distributors: Purchasing from non-authorized dealers may result in faulty, mislabeled, or counterfeit parts without manufacturer warranty. Always source from reputable suppliers.

• Firmware Considerations: For applications requiring specific firmware, confirm compatibility as the product may not include the latest firmware revisions.

• Environmental Limits: Ensure operation within the specified temperature range (-25°C to +60°C) to avoid performance issues.

• Installation: Proper installation by qualified personnel is required to ensure safety and compliance with local regulations.

Product Applications

• Motor Control: Ideal for isolating motors to prevent hazardous motion in safety-critical systems.

• Industrial Automation: Used in feedback circuits for modern safety applications, ensuring reliable control in automated systems.

• Safety Systems: Suitable for applications requiring redundant contactors and mechanically linked contacts, such as emergency stop circuits and machine guarding.

• Manufacturing: Employed in industrial environments like manufacturing plants where precise control and safety are paramount.

• HVAC Systems: Can be used in heating, ventilation, and air conditioning systems requiring reliable switching and safety features.

• Process Control: Applicable in process industries where safety contactors are needed to manage equipment operation safely.

Note: For additional technical documentation, refer to the Rockwell Automation Technical Documentation Center or Literature Library.
