100-C60D*00 Allen‑Bradley contactor

Description

100-C60D*00 Allen‑Bradley contactor

Product Dimensions：

Product Description

The Allen‑Bradley 100-C60D*00 is a general-purpose contactor from the Bulletin 100-C series manufactured by Rockwell Automation. It is designed for switching resistive, inductive, and motor loads in industrial control applications. The contactor is known for its reliability, compact design, and ease of integration into control panels and motor starters. It features a durable construction with high electrical and mechanical life, making it suitable for demanding environments. The “D” in the model number indicates a specific coil voltage type, which can vary depending on the last two digits of the model code (e.g., 100-C60DJ00 = 24V DC coil).

Product Parameters

• Product Line: Allen‑Bradley Bulletin 100-C Contactors
• Model: 100-C60D*00
• Rated Operational Current (Ie): 60 A
• Motor Load Rating: Up to 30 kW at 400 V AC
• Voltage Rating:
  • Main Circuit: Up to 600 V AC
  • Control Coil: Varies (e.g., 24V DC, 110V AC, 230V AC) — refer to exact model suffix
• Poles: 3 poles
• Auxiliary Contacts: Optional, depending on configuration
• Mechanical Life: Up to 10 million operations
• Electrical Life: Up to 1 million operations at rated load
• Operating Temperature: –25°C to +60°C
• Enclosure Rating: Open type (IP00), suitable for panel mounting
• Certifications: UL, CSA, CE, IEC compliant

Product Advantages

• Robust Performance: Designed for high endurance in heavy-duty industrial applications.
• Compact Size: Space-saving design allows for dense panel layouts.
• Flexible Coil Options: Supports a wide range of control voltages for global compatibility.
• Ease of Maintenance: Modular design simplifies replacement and coil changes.
• Wide Application Range: Suitable for various load types including motors, resistors, and lighting.
• Global Standards Compliance: Meets major international safety and performance standards.

Precautions

• Coil Voltage Matching: Ensure the coil voltage matches the control circuit voltage to prevent malfunction or damage.
• Mounting Orientation: Mount the contactor in the specified orientation to ensure proper operation and heat dissipation.
• Load Type Consideration: Verify that the contactor is appropriately rated for the type of load (inductive, resistive, motor).
• Environmental Conditions: Avoid exposure to corrosive atmospheres, extreme humidity, or vibration beyond specified limits.
• Wiring Safety: Follow all local electrical codes and ensure proper insulation and secure connections.
• Maintenance: Regularly inspect contacts for wear and replace auxiliary contacts or coils as needed.

Product Applications

• Motor Control: Widely used in motor starters and control circuits for pumps, fans, conveyors, and compressors.
• Industrial Automation: Integrated into control panels for switching resistive and inductive loads in manufacturing machinery.
• HVAC Systems: Applied in heating, ventilation, and air conditioning systems for reliable load switching.
• Lighting Control: Used in commercial and industrial lighting systems for high-current switching.
• Power Distribution: Deployed in power switching and distribution systems for isolating and protecting circuits.
